2SD5011 Power Mosfet Transistor isc Silicon NPN Power Transistor

: Large Image : 2SD5011 Power Mosfet Transistor isc Silicon NPN Power Transistor

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	2SD5011

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8000pcs

Contact Now

Detailed Product Description

Collector-Base Voltage:	1500 V	Collector-Emitter Voltage:	800 V
Emitter-Base Voltage:	6 V	Collector Current- Continuous:	3.5 A
Collector Current-Peak:	10 A	Collector Power Dissipation @ TC=25℃:	50 W
Junction Temperature:	150 ℃	Storage Temperature Range:	-55~150 ℃
Highlight:	power mosfet ic , multi emitter transistor

isc Silicon NPN Power Transistor 2SD5011

DESCRIPTION

·High Breakdown Voltage- : VCBO= 1500V (Min)

·High Switching Speed

·High Reliability

·Built-in Damper Diode

APPLICATIONS

·Designed for color TV horizontal output applications

ABSOLUTE MAXIMUM RATINGS(Ta=25℃)

SYMBOL	PARAMETER	VALUE	UNIT
VCBO	Collector-Base Voltage	1500	V
VCEO	O Collector-Emitter Voltage	800	V
VEBO	Emitter-Base Voltage	6	V
IC C	Collector Current- Continuous	3.5	A
ICM	Collector Current-Peak	10	A
PC	Collector Power Dissipation @ TC=25℃	50	W
TJ	Junction Temperature	150	℃
Tstg	Storage Temperature Range	-55~150	℃
