Vnd600sp Double Channel High Side Solid State Relay Double Diode Model

VND600SP DOUBLE CHANNEL HIGH SIDE SOLID STATE RELAY double diode model

■ DC SHORT CIRCUIT CURRENT: 25 A

■ CMOS COMPATIBLE INPUTS

■ PROPORTIONAL LOAD CURRENT SENSE

■ UNDERVOLTAGE AND OVERVOLTAGEn SHUT-DOWN

■ OVERVOLTAGE CLAMP

■ THERMAL SHUT DOWN

■ CURRENT LIMITATION

■ VERY LOW STAND-BY POWER DISSIPATION

■ PROTECTION AGAINST: n LOSS OF GROUND AND LOSS OF VCC

■ REVERSE BATTERY PROTECTION (*)

DESCRIPTION The VND600SP is a monolithic device made using STMicroelectronics VIPower M0-3 technology. It is intended for driving resistive or inductive loads with one side connected to ground. Active VCC pin voltage clamp protects the device against low energy spikes (see ISO7637

transient compatibility table). This device has two channels in high side configuration; each channel has an analog sense output on which the sensing current is proportional (according to a known ratio) to the corresponding load current. Built-in thermal shut-down and outputs current limitation protect the chip from over temperature and short circuit. Device turns off in case of ground pin disconnection.
