LM78LXX Series

3-Terminal Positive Regulators

General Description

The LM78LXX series of three terminal positive regulators is available with several fixed output voltages making them useful in a wide range of applications. When used as a zener diode/resistor combination replacement, the LM78LXX usually results in an effective output impedance improvement of two orders of magnitude, and lower quiescent current. These regulators can provide local on card regulation, eliminating the distribution problems associated with single point regulation. The voltages available allow the LM78LXX to be used in logic systems, instrumentation, HiFi, and other solid state electronic equipment.

The LM78LXX is available in the plastic TO-92 (Z) package, the plastic SO-8 (M) package and a chip sized package (8-Bump micro SMD) using National’s micro SMD package technology. With adequate heat sinking the regulator can deliver 100 mA output current. Current limiting is included to limit the peak output current to a safe value. Safe area protection for the output transistors is provided to limit internal power dissipation. If internal power dissipation becomes too high for the heat sinking provided, the thermal shutdown circuit takes over preventing the IC from overheating.

Features

• LM78L05 in micro SMD package

• Output voltage tolerances of ±5% over the temperature range

• Output current of 100 mA

• Internal thermal overload protection

• Output transistor safe area protection

• Internal short circuit current limit

• Available in plastic TO-92 and plastic SO-8 low profile packages

• No external components

• Output voltages of 5.0V, 6.2V, 8.2V, 9.0V, 12V, 15V

Connection Diagrams

Absolute Maximum Ratings (Note 1)

If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/ Distributors for availability and specifications.

Power Dissipation (Note 5)                                     Internally Limited

Input Voltage                                                                              35V

Storage Temperature                                             −65˚C to +150˚C

Operating Junction Temperature

   SO-8                                                                          0˚C to 125˚C

   micro SMD                                                                −40˚C to 85˚C

Soldering Information

   Infrared or Convection (20 sec.)                                            235˚C

   Wave Soldering (10 sec.)                                     260˚C (lead time)

ESD Susceptibility (Note 2)                                                          1kV

Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Electrical specifications do not apply when operating the device outside of its stated operating conditions.

Note 5: Typical thermal resistance values for the packages are:

              Z Package: θ_JC = 60 ˚C/W, = θ_JA = 230 ˚C/W

              M Package: θ_JA = 180 ˚C/W

              micro SMD Package: θ_JA = 230.9˚C/W
