Product Details:
Payment & Shipping Terms:
|
| Peak Reverse Voltage, Non Repetitive: | 110 V | Reverse Voltage: | 100 V |
|---|---|---|---|
| Peak Forward Surge Current: | 50 A | Repetitive Peak Forward Current: | 15 A |
| Average Forward Current: | 2 A | Junction And Storage Temperature: | –65...+175℃ |
| Highlight: | diode rectifier circuit,bridge rectifier circuit |
||
BYV27/...
Ultra Fast Silicon Mesa Rectifiers
Features
• Controlled avalanche characteristic
• Low forward voltage
• Ultra fast recovery time
• Glass passivated junction
• Hermetically sealed package
Applications
Very fast rectifier e.g. for switch mode power supply
Absolute Maximum Ratings Tj = 25℃
| Parameter | Test Conditions | Type | Symbol | Value | Unit |
|---|---|---|---|---|---|
| Peak reverse voltage, non repetitive | BYV27/50 | VRSM | 55 | V | |
| BYV27/100 | VRSM | 110 | V | ||
| BYV27/150 | VRSM | 165 | V | ||
| BYV27/200 | VRSM | 220 | V | ||
| Reverse voltage=Repetitive peak reverse voltage | BYV27/50 | VR=VRRM | 50 | V | |
| BYV27/100 | VR=VRRM | 100 | V | ||
| BYV27/150 | VR=VRRM | 150 | V | ||
| BYV27/200 | VR=VRRM | 200 | V | ||
| Peak forward surge current | tp=10ms, half sinewave | IFSM | 50 | A | |
| Repetitive peak forward current | IFRM | 15 | A | ||
| Average forward current | IFAV | 2 | A | ||
| Pulse energy in avalanche mode, non repetitive (inductive load switch off) |
I(BR)R=0.6A, Tj =175℃ |
ER | 20 | mJ | |
| Junction and storage temperature range | Tj =Tstg | –65...+175 | ℃ |
Dimensions in mm
