SN74HCT244DWR Electronic Components IC Octal Buffers And Line Drivers With 3 State Outputs

: Large Image : SN74HCT244DWR Electronic Components IC Octal Buffers And Line Drivers With 3 State Outputs

Product Details:

Place of Origin:	Original
Brand Name:	TI
Certification:	Original Factory Pack
Model Number:	SN74HCT244DWR

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	290PCS

Contact Now

Detailed Product Description

Supply Voltage Range, VCC:	–0.5 V To 7 V	Input Clamp Current, IIK (VI < 0 Or VI > VCC):	±20 MA
Output Clamp Current, IOK:	±20 MA	Continuous Output Current, IO:	±35 MA
Continuous Current Through VCC Or GND:	±70 MA
High Light:	integrated circuit ic , integrated circuit components

SN74HCT244DWR Electronic Components IC Octal Buffers And Line Drivers With 3 State Outputs

SN74HCT244DWR Electronic Components IC Octal Buffers And Line Drivers With 3 State Outputs ♦Operating Voltage Range of 4.5 V to 5.5 V

♦High-Current Outputs Drive Up To 15 LSTTL Loads

♦Low Power Consumption, 80-µA Max ICC

♦Typical tpd = 13 ns

♦±6-mA Output Drive at 5 V

♦Low Input Current of 1 µA Max

♦Inputs Are TTL-Voltage Compatible

♦3-State Outputs Drive Bus Lines or Buffer Memory Address Registers

description/ordering information

These octal buffers and line drivers are designed specifically to improve both the performance and density of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. The ’HCT244 devices are organized as two 4-bit buffers/drivers with separate output-enable (OE) inputs. When OE is low, the device passes noninverted data from the A inputs to the Y outputs. When OE is high, the outputs are in the high-impedance state.

SN74HCT244DWR Electronic Components IC Octal Buffers And Line Drivers With 3 State Outputs
