4N33 Integrated Circuit Chip , Power Electronics Components Photodarlington Optocoupler

China 4N33 Integrated Circuit Chip , Power Electronics Components Photodarlington Optocoupler supplier

Large Image :  4N33 Integrated Circuit Chip , Power Electronics Components Photodarlington Optocoupler

Product Details:

Place of Origin: Original
Brand Name: ANTERWELL
Certification: Original Factory Pack
Model Number: 4N33

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiation
Packaging Details: DIP-6
Delivery Time: 1 Day
Payment Terms: T/T, Western Union,PayPal, Western Union
Supply Ability: 8200PCS
Detailed Product Description
Continuous Forward Current: 60mA Power Dissipation: 100 MW
Transceiver:: 3V Temperature (TJ ): -55°C -- 150°C
Payment Term: T/T, Paypal, Western Union Package: DIP-6

4N33 Integrated Circuit Chip

PHOTODARLINGTON OPTOCOUPLER



RoHS peak reflow temperature rating 245C IEEE 802.3af/ANSI X3.263 compliant performance Designed for IP phone or switch applications



STOCK LIST



C.I SN74LS244N TI 64AH70K/5ACCLLK DIP-20
C.I 74HC238D NXP 1640 SOP-16
C.I P8255A5 (not L8320146) INTEL L5171029 DIP-40
C.I HEF4051BT NXP 1622+ SOP-16
C.I SERIAL NUMBER
IBUTTON DS1990A-F5+
DALLAS 1631 BUTTON
C.I M27C2001-10F1 ST 1211K CDIP 32
TRANS IRF540NPBF IR P632D TO-220
TRIAC BT151-500R NXP PJA603 TO-220
C.I MC908MR16CFUE FREESCAL 1341 LQFP-64
C.I 74HC245DB,118 NXP 1619 SSOP-20
C.I MCP130T-315I/TT MICROCHIP PLEP SOT23-3
DIODO RGF1M-E3/67A VISHAY RM/5B SMA
C.I 74HC244DB,118 NXP 1418 SSOP-20
C.I 74LVC139D NXP 1213 SOP-16
C.I LD1086V33 ST 829/833 TO-220
DIODO TPD4E001DBVR TI NFY5 SOT23-6
TRIAC BT151-500R NXP PJA603 TO-220
S5M-E3/57T VISHAY 1632/5M SMC
DIODO LED VSLB3940 VISHAY 10+ DIP-2
MMBT3906LT1G ON 1642/2A SOT-23
DIODO BAS16LT1G ON SEMI 1640/A6 SOT-23
MBR3045CTP DIODES 1024 TO-220
GBU6M VISHAY 1510L DIP-4
GBU608 SEP 16+ DIP-4
SENSOR KTY11-6
Q62705-K246
T6/S76 TO-92
C.I AD590KH AD 1406 CAN3
C.I ICL7660CBAZ INTERSIL V1608BA SOP-8
C.I PC817C SHARP H41 DIP-4
TRANS TIP127 (ROHS) ST 608 TO-220
OPTO 4N25M FSC 645Q

DIP-6



Feature

• Very High Current Transfer Ratio, 500% Min.

• High Isolation Resistance, 1011 Ω Typical

• Standard Plastic DIP Package

• Underwriters Lab File #E52744

• VDE Approvals #0884



DESCRIPTION



The 4N32 and 4N33 are optically coupled isolators with a Gallium Arsenide infrared LED and a silicon photodarlington sensor. Switching can be achieved while maintaining a high degree of isolation between driving and load circuits.



These optocouplers can be used to replace reed and mercury relays with advantages of long life, high speed switching and elimination of magnetic fields.



Maximum Ratings

Emitter Peak Reverse Voltage ........................................3 V

Continuous Forward Current .........................60 mA

Power Dissipation at 25°C..........................100 mW

Derate Linearly from 55°C....................1.33 mW/°C

Detector Collector-Emitter Breakdown Voltage, BVCEO .......................................................... 30 V

Emitter-Base Breakdown Voltage, BVEBO ............................................................. 8V

Collector-Base Breakdown Voltage, BVCBO .......................................................... 50 V

Emiter-Collector Breakdown Voltage, BVECO ............................................................ 5 V

Collector (load) Current...............................125 mA

Power Dissipation at 25°C Ambient ...........150 mW

Derate Linearly from 25°C......................2.0 mW/°C

Package Total Dissipation at 25°C Ambient .............250 mW

Derate Linearly from 25°C......................3.3 mW/°C

Isolation Test Voltage.........................5300

VACRMS Between Emitter and Detector, Standard Climate: 23°C/50%RH,

DIN 50014 Leakage Path ........................................ 7 mm min.

Air Path................................................... 7 mm min.
