Core:: | 1.2V | I/O:: | 3.3V Or 2.5V |
---|---|---|---|
Transceiver:: | 3.3V | Junction Temperature (TJ ): | 125°C |
Applications: | Laser/Network Printer | ||
High Light: | electronics ic chip,integrated circuit ic |
General Description
The KSZ9021RL is a completely integrated triple speed (10Base-T/100Base-TX/1000Base-T) Ethernet Physical Layer Transceiver for transmission and reception of data over standard CAT-5 unshielded twisted pair (UTP) cable. The KSZ9021RL provides the Reduced Gigabit Media Independent Interface (RGMII) for direct connection to RGMII MACs in Gigabit Ethernet Processors and Switches for data transfer at 10/100/1000Mbps speed.
The KSZ9021RL reduces board cost and simplifies board layout by using on-chip termination resistors for the four differential pairs and by integrating a LDO controller to drive a low cost MOSFET to supply the 1.2V core
The KSZ9021RL provides diagnostic features to facilitate system bring-up and debugging in production testing and in product deployment. Parametric NAND tree support enables fault detection between KSZ9021 I/Os and board. Micrel LinkMD® TDR-based cable diagnostics permit identification of faulty copper cabling. Remote and local loopback functions provide verification of analog and digital data paths.
The KSZ9021RL is available in a 64-pin, lead-free E-LQFP package, and is offered as the KSZ9021RN in the smaller 48-pin QFN package (See Ordering Information).
Ordering Information
Part Number | Temp. Range | Package | Lead Finish | Description |
KSZ9021RL | 0°C to 70°C | 64-Pin E-LQFP | Pb-Free | RGMII, Commercial Temperature, 64-E-LQFP |
KSZ9021RLI (1) | -40°C to 85°C | 64-Pin E-LQFP | Pb-Free | RGMII, Industrial Temperature, 64-E-LQFP |
KSZ9021RN | 0°C to 70°C | 48-Pin QFN | Pb-Free | RGMII, Commercial Temperature, 48-QFN |
KSZ9021RNI (1) | -40°C to 85°C | 48-Pin QFN | Pb-Free | RGMII, Industrial Temperature, 48-QFN |
RGMII Timing
The KSZ9021RL/RN RGMII timing conforms to the timing requirements per the RGMII Version 1.3 Specification.
