Product Details:
Payment & Shipping Terms:
|
Average Forward Current: | 100 MA | Instanious Forward Current: | 200 MA |
---|---|---|---|
Total Power Dissipation*1: | 200 MW | PZSM: | 15 W |
Junction Temperature: | 150 °C | ||
High Light: | electronics ic chip,integrated circuit components |
For stabilization of power supply
Features
• Mini type package (3-pin)
• Allowing to achieve a high-density set
• Sharp rising performance
• Wide voltage range: VZ = 2.0 V to 36 V
Marking Symbol
Refer to the list of the electrical
characteristics within part numbers
(Example)
MAZ3020: 2.0
MAZ3082-H: 8.2H Note)
L/M/H marked products will be supplied unless other wise specified
■ Absolute Maximum Ratings Ta = 25°C
Parameter | Symbol | Rating | Unit |
Average forward current | IF(AV) | 100 | mA |
Instanious forward current | IFRM | 200 | mA |
Total power dissipation*1 | Ptot | 200 | mW |
Non-repetitive reverse surge power dissipation*2 | PZSM | 15 | W |
Junction temperature | Tj | 150 | °C |
Storage temperature | Tstg | -55 to +150 | °C |
