AQW254 Integrated Circuit Chip PhotoMOS RELAYS solid state relay

: Large Image : AQW254 Integrated Circuit Chip PhotoMOS RELAYS solid state relay

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	AQW254

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	10000pcs

Contact Now

Detailed Product Description

(Input) LED Forward Current:	50 MA	(Input) LED Reverse Voltage:	3 V
(Input) Peak Forward Current:	1 A	(Input) Power Dissipation:	75 MW
Total Power Dissipation:	850 MW	I/O Isolation Voltage:	1,500 V AC
High Light:	electronics ic chip , integrated circuit components

HE (High-function Economy) Type

[2-Channel (Form A) Type]

PhotoMOS RELAYS

FEATURES

1. Compact 8-pin DIP size

The device comes in a compact (W) 6.4×(L) 9.78×(H) 3.9 mm (W) .252×(L) .385×(H) .154 inch , 8-pin DIP size (through hole terminal type).

2. Applicable for 2 Form A use as well as two independent 1 Form A use

3. Controls low-level analog signals

PhotoMOS relays feature extremely low closed-circuit offset voltage to enable control of low-level analog signals without distortion.

4. High sensitivity, low ON resistance

Can control a maximum 0.16 A (AQW254) load current with a 5 mA input current. Low ON resistance of 16 Ω (AQW254). Stable operation because there are no metallic contact parts.

5. Low-level off state leakage current

The SSR has an off state leakage current of several miliamperes, whereas the PhotoMOS relay has only 100 pA even with the rated load voltage of 400 V (AQW254).

6. Low thermal electromotive force (Approx. 1 µV)

TYPICAL APPLICATIONS

• High-speed inspection machines

• Data communication equipment

• Telephone equipment

AQW254 Integrated Circuit Chip PhotoMOS RELAYS solid state relay

Absolute maximum ratings (Ambient temperature: 25°C / 77°F)

Item		Symbol	AQW254(A)	Remarks
Input	LED forward current	I_F	50 mA
	LED reverse voltage	V_R	3 V
	Peak forward current	L_FP	1 A	f = 100 Hz, Duty factor = 0.1%
	Power dissipation	P_in	75 mW
Output	Load voltage (peak AC)	V_L	400 V
	Continuous load current	I_L	0.12 A (0.16 A)	A connection: Peak AC, DC ( ): in case of using only 1 channel
	Peak load current	I_peak	0.36 A	A connection: 100 ms (1 shot), V_L = DC
	Power dissipation	P_out	800 mW
Total power dissipation		P_T	850 mW
I/O isolation voltage		V_iso	1,500 V AC	Between input and output/between contact sets
Temperature limits	Operating	T_opr	–40°C to +85°C –40°F to +185°F	Non-condensing at low temperatures
Temperature limits	Storage	T_stg	–40°C to +100°C –40°F to +212°F
