CS4351
192 kHz Stereo DAC with 2 Vrms Line Out
Features
• Multi-Bit Delta-Sigma Modulator
• 24-Bit Conversion
• Up to 192 kHz Sample Rates
• 112 dB Dynamic Range
• -100 dB THD+N
• +3.3 V, +9 to 12 V, and VL Power Supplies
• 2 Vrms Output into 5 kΩ AC Load
• Digital Volume Control with Soft Ramp
– 119 dB Attenuation
– 1/2 dB Step Size
– Zero Crossing Click-Free Transitions
• ATAPI Mixing
• Low Clock Jitter Sensitivity
• Popguard® Technology for Control of Clicks and Pops
Description
The CS4351 is a complete stereo digital-to-analog system including digital interpolation, fifth-order multi-bit delta-sigma digital-to-analog conversion, digital de-emphasis, volume control, channel mixing, analog filtering, and on-chip 2 Vrms line-level driver. The advantages of this architecture include ideal differential linearity, no distortion mechanisms due to resistor matching errors, no linearity drift over time and temperature, high tolerance to clock jitter, and a minimal set of external components.
The CS4351 is available in a 20-pin TSSOP package in both Commercial (-10°C - +70°C) and Automotive grades (-40°C to +85°C). The CDB4351 Customer Demonstration board is also available for device evaluation and implementation suggestions.
These features are ideal for cost-sensitive, 2-channel audio systems including DVD players, A/V receivers, set-top boxes, digital TVs and VCRs, mini-component systems, and mixing consoles.
ABSOLUTE MAXIMUM RATINGS
(GND = 0 V; all voltages with respect to ground.)
Parameters | Symbol | Min | Max | Units |
---|---|---|---|---|
DC Power Supply High Voltage Analog power Low Voltage Analog power Digital power Interface power |
VA_H VA VD VL |
-0.3 -0.3 -0.3 -0.3 |
14 3.63 3.63 3.63 |
V V V V |
Input Current, Any Pin Except Supplies |
Iin | - | ±10 | mA |
Digital Input Voltage Digital Interface | VIN-L | -0.3 | VL+ 0.4 | V |
Ambient Operating Temperature (power applied) | TA | -55 | 125 | °C |
Storage Temperature | Tstg | -65 | 150 | °C |
Operation at or beyond these limits may result in permanent damage to the device. Normal operation is not guaranteed at these extremes.
