74HC165D Electronic IC Chips 8-bit parallel-in/serial-out shift register

74HC/HCT165

8-bit parallel-in/serial-out shift register

FEATURES

• Asynchronous 8-bit parallel load

• Synchronous serial input

• Output capability: standard

• I_CC category: MSI

GENERAL DESCRIPTION

The 74HC/HCT165 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL). They are specified in compliance with JEDEC standard no. 7A.

The 74HC/HCT165 are 8-bit parallel-load or serial-in shift registers with complementary serial outputs (Q7 and Q7) available from the last stage. When the parallel load (PL) input is LOW, parallel data from the D0 to D7 inputs are loaded into the register asynchronously.

When PL is HIGH, data enters the register serially at the Ds input and shifts one place to the right (Q0 → Q1 → Q2, etc.) with each positive-going clock transition. This feature allows parallel-to-serial converter expansion by tying the Q7 output to the DS input of the succeeding stage.

The clock input is a gated-OR structure which allows one input to be used as an active LOW clock enable (CE) input. The pin assignment for the CP and CE inputs is arbitrary and can be reversed for layout convenience. The LOW-to-HIGH transition of input CE should only take place while CP HIGH for predictable operation. Either the CP or the CE should be HIGH before the LOW-to-HIGH transition of PL to prevent shifting the data when PL is activated.

APPLICATIONS

• Parallel-to-serial data conversion

QUICK REFERENCE DATA

GND = 0 V; T_amb = 25 °C; t_r = t_f = 6 ns

Notes

1. C_PD is used to determine the dynamic power dissipation (P_D in µW):

      P_D = C_PD × V_CC² × f_i + ∑ (C_L × V_CC² × f_o) where:

   f_i = input frequency in MHz

   f_o = output frequency in MHz

   ∑ (C_L × V_CC² × f_o) = sum of outputs

   C_L = output load capacitance in pF

   V_CC = supply voltage in V

2. For HC the condition is V_I = GND to V_CC

    For HCT the condition is V_I = GND to V_CC − 1.5 V
