TEMT6000X01 Electronic IC Chips Ambient Light Sensor, RoHS Compliant

: Large Image : TEMT6000X01 Electronic IC Chips Ambient Light Sensor, RoHS Compliant

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	TEMT6000X01

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	9000pcs

Contact Now

Detailed Product Description

Collector Emitter Voltage:	6 V	Emitter Collector Voltage:	1.5 V
Collector Current:	20 MA	Power Dissipation:	100 MW
Junction Temperature:	100 °C	Operating Temperature:	- 40 To + 100 °C
High Light:	electronic integrated circuit , linear integrated circuits

TEMT6000X01

Ambient Light Sensor, RoHS Compliant, Released for Lead (Pb)-free Reflow Soldering, AEC-Q101 Released

FEATURES

• Package type: surface mount

• Package form: 1206

• Dimensions (L x W x H in mm): 4 x 2 x 1.05

• Product designed and qualified acc. AEC-Q101 for the automotive market

• High photo sensitivity

• Adapted to human eye responsivity

• Angle of half sensitivity: ϕ = ± 60°

• Floor life: 72 h, MSL 4, acc. J-STD-020

• Lead (Pb)-free reflow soldering

• Lead (Pb)-free component in accordance with RoHS 2002/95/EC and WEEE 2002/96/EC

APPLICATIONS

Ambient light sensor for control of display backlight dimming in LCD displays and keypad backlighting of mobile devices and in industrial on/off-lighting operation.

• Automotive sensors

• Mobile phones

• Notebook computers

• PDA’s

• Cameras

• Dashboards

DESCRIPTION

TEMT6000X01 ambient light sensor is a silicon NPN epitaxial planar phototransistor in a miniature transparent 1206 package for surface mounting. It is sensitive to visible light much like the human eye and has peak sensitivity at 570 nm.

ABSOLUTE MAXIMUM RATINGS

PARAMETER	TEST CONDITION	SYMBOL	VALUE	UNIT
Collector emitter voltage		V_CEO	6	V
Emitter collector voltage		V_ECO	1.5	V
Collector current		I_C	20	mA
Power dissipation		P_V	100	mW
Junction temperature		Tj	100	°C
Operating temperature range		Tamb	- 40 to + 100	°C
Storage temperature range		Tstg	- 40 to + 100	°C
Soldering temperature	Acc. reflow solder profile fig. 8	Tsd	260	°C
Thermal resistance junction/ambient	Soldered on PCB with pad dimensions: 4 mm x 4 mm	R_thJA	450	K/W

Note Tamb = 25 °C, unless otherwise specified
