HCPL-0302 Electronic IC Chip Output Current IGBT Gate Drive Optocoupler

: Large Image : HCPL-0302 Electronic IC Chip Output Current IGBT Gate Drive Optocoupler

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	HCPL-0302

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8700pcs

Contact Now

Detailed Product Description

Storage Temperature:	–55 To 125 °C	Operating Temperature:	–40 To 100 °C
Average Input Current:	20 MA	Supply Voltage:	–0.5 To 35 V
Output Power Dissipation:	250 MW	Input Power Dissipation:	45 MW
High Light:	electronic integrated circuit , linear integrated circuits

HCPL-3020/HCPL-0302

0.4 Amp Output Current IGBT Gate Drive Optocoupler

Description

The HCPL-3020 and HCPL-0302 consist of a GaAsP LED optically coupled to an integrated circuit with a power output stage. These optocouplers are ideally suited for driving power IGBTs and MOSFETs used in motor control inverter applications. The high operating voltage range of the output stage provides the drive voltages required by gate-controlled devices. The voltage and current supplied by this optocoupler makes it ideally suited for directly driving small or medium power IGBTs. For IGBTs with higher ratings, the HCPL-0314/3140 (0.6 A), HCPL-3150 (0.6 A) or HCPL-3120 (2.5 A) gate drive opto-couplers can be used.

Features

• 0.4 A maximum peak output current

• 0.2 A minimum peak output current

• High speed response: 0.7 µs maximum propagation delay over temperature range

• Ultra high CMR: minimum 10 kV/µs at V_CM = 1000 V

• Bootstrappable supply current: maximum 3 mA

• Wide operating temperature range: –40°C to 100°C

• Wide V_CC operating range: 10 V to 30 V over temperature range

• Available in DIP 8 and SO-8 packages

• Safety approvals: UL approval, 3750 VRMS for 1 minute

• CSA approval

• IEC/EN/DIN EN 60747-5-2 approval

V_IORM = 630 V_PEAK (HCPL-3020),

V_IORM = 566 V_PEAK (HCPL-0302)

Applications

• Isolated IGBT/power MOSFET gate drive

• AC and brushless DC motor drives

• Industrial inverters

• Air conditioner

• Washing machine

• Induction heater for cooker

• Switching power supplies (SPS)

Functional Diagram

HCPL-0302 Electronic IC Chip Output Current IGBT Gate Drive Optocoupler

Absolute Maximum Ratings

Parameter	Symbol	Min.	Max.	Units	Note
Storage Temperature	T_S	-55	125	°C
Operating Temperature	T_A	-40	100	°C
Average Input Current	I_F(AVG)		20	mA	1
Peak Transient Input Current (<1 µs pulse width, 300 pps)	I_F(TRAN)		1.0	A
Reverse Input Voltage	V_R		5	V
“High” Peak Output Current	I_OH(PEAK)		0.4	A	2
“Low” Peak Output Current	I_OL(PEAK)		0.4	A	2
Supply Voltage	V_CC – V_EE	–0.5	35	V
Output Voltage	V_O(PEAK)	–0.5	V_CC	V
Output Power Dissipation	P_O		250	mW	3
Input Power Dissipation	P_I		45	mW	4
Lead Solder Temperature	260°C for 10 sec., 1.6 mm below seating plane
Solder Reflow Temperature Profile	See Package Outline Drawings section

Notes:

1. Derate linearly above 70°C free air temperature at a rate of 0.3 mA/°C.

2. Maximum pulse width = 10 µs, maximum duty cycle = 0.2%. This value is intended to allow for component tolerances for designs with IO peak minimum = 0.2 A. See Application section for additional details on limiting IOL peak.

3. Derate linearly above 85°C, free air temperature at the rate of 4.0 mW/°C.

4. Input power dissipation does not require derating.
