Product Details:
Payment & Shipping Terms:
|
| Supply Voltage: | 43 V | Supply Voltage For Full Short Circuit Protection: | 34 V |
|---|---|---|---|
| Operating Temperature: | -40 ...+150 °C | Storage Temperature: | -55 ...+150 °C |
| Input Voltage (DC): | -10 ... +16 V | Current Through Input Pin (DC): | ±2.0 MA |
| High Light: | electronic integrated circuit,linear integrated circuits |
||
BTS711L1
Smart Four Channel Highside Power Switch
Features
• Overload protection
• Current limitation
• Short-circuit protection
• Thermal shutdown
• Overvoltage protection (including load dump)
• Fast demagnetization of inductive loads
• Reverse battery protection1)
• Undervoltage and overvoltage shutdown with auto-restart and hysteresis
• Open drain diagnostic output
• Open load detection in ON-state
• CMOS compatible input
• Loss of ground and loss of Vbb protection
• Electrostatic discharge (ESD) protection
Application
• µC compatible power switch with diagnostic feedback for 12 V and 24 V DC grounded loads
• All types of resistive, inductive and capacitive loads
• Replaces electromechanical relays and discrete circuits
General Description
N channel vertical power FET with charge pump, ground referenced CMOS compatible input and diagnostic feedback, monolithically integrated in Smart SIPMOS technology. Providing embedded protective functions.
Product Summary
|
Overvoltage Protection Vbb(AZ) 43 V Operating voltage Vbb(on) 5.0 ... 34 V |
||||
|
active channels: |
one |
two parallel |
four parallel | |
|
On-state resistance RON Nominal load current IL(NOM) Current limitation IL(SCr) |
200 1.9 4 |
100 2.8 4 |
50 4.4 4 |
mΩ A A |
