TLC393CPW Electronic IC Chips DUAL MICROPOWER LinCMOS VOLTAGE COMPARATOR

TLC193 TLC393

DUAL MICROPOWER LinCMOS^TM VOLTAGE COMPARATOR

• Very Low Power . . . 110 µW Typ at 5 V

• Fast Response Time ...t_PLH = 2.5 µs Typ With 5-mV Overdrive

• Single Supply Operation:

  TLC393C . . . 3 V to 16 V

  TLC393I . . . 3 V to 16 V

  TLC393Q . . . 4 V to 16 V

  TLC393M . . . 4 V to 16 V

  TLC193M . . . 4 V to 16 V

• On-Chip ESD Protection

description

The TLC193 and TLC393 consist of dual independent micropower voltage comparators designed to operate from a single supply. They are functionally similar to the LM393 but uses one-twentieth the power for similar response times. The open-drain MOS output stage interfaces to a variety of loads and supplies. For a similar device with a push-pull output configuration (see the TLC3702 data sheet).

Texas Instruments LinCMOS^TM process offers superior analog performance to standard CMOS processes. Along with the standard CMOS advantages of low power without sacrificing speed, high input impedance, and low bias currents, the LinCMOS^TM process offers extremely stable input offset voltages, even with differential input stresses of several volts. This characteristic makes it possible to build reliable CMOS comparators.

The TLC393C is characterized for operation over the commercial temperature range of T_A = 0°C to 70°C. The TLC393I is characterized for operation over the extended industrial temperature range of T_A = −40°C to 85°C. The TLC393Q is characterized for operation over the full automotive temperature range of T_A = −40°C to 125°C. The TLC193M and TLC393M are characterized for operation over the full military temperature range of T_A = −55°C to 125°C.

absolute maximum ratings over operating free-air temperature range (unless otherwise noted)†

Supply voltage range, V_DD (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . − 0.3 V to 18 V

Differential input voltage, V_ID (see Note 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±18 V

Input voltage range, V_I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . − 0.3 V to V_DD

Output voltage range, V_O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . − 0.3 V to 16 V

Input current, I_I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±5 mA

Output current, I_O (each output) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 mA

Total supply current into V_DD  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 mA

Total current out of GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 mA

Continuous total power dissipation  . . . . . . . . . . . . . . . . . . . . . . . . . .  See Dissipation Rating Table

Operating free-air temperature range: TLC393C  . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to 70°C

                                                             TLC393I . . . . . . . . . . . . . . . . . . . . . . . . . . . − 40°C to 85°C

                                                             TLC393Q . . . . . . . . . . . . . . . . . . . . . . . . . − 40°C to 125°C

                                                             TLC393M . . . . . . . . . . . . . . . . . . . . . . . . . − 55°C to 125°C

                                                             TLC193M . . . . . . . . . . . . . . . . . . . . . . . . . − 55°C to 125°C

Storage temperature range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . − 65°C to 150°C

Case temperature for 60 seconds: FK package  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260°C

Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D or P package  . . . . . . . . 260°C

Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: JG package  . . . . . . . . . . . 300°C

† Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

NOTES:

1. All voltage values, except differential voltages, are with respect to network ground.

2. Differential voltages are at IN+ with respect to IN−.
