MC14551BCP Electronic IC Chips Quad 2-Channel Analog Multiplexer

: Large Image : MC14551BCP Electronic IC Chips Quad 2-Channel Analog Multiplexer

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	MC14551BCP

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	7500pcs

Contact Now

Detailed Product Description

DC Supply Voltage:	– 0.5 To + 18.0 V	Input Or Output Voltage:	– 0.5 To VDD + 0.5 V
Input Current:	± 10 MA	Switch Through Current:	± 25 MA
Ambient Temperature:	– 55 To + 125 ℃	Storage Temperature:	– 65 To + 150 ℃
High Light:	electronic integrated circuit , linear integrated circuits

MC14551B

Quad 2-Channel Analog Multiplexer/Demultiplexer

The MC14551B is a digitally–controlled analog switch. This device implements a 4PDT solid state switch with low ON impedance and very low OFF Leakage current. Control of analog signals up to the complete supply voltage range can be achieved.

• Triple Diode Protection on All Control Inputs

• Supply Voltage Range = 3.0 Vdc to 18 Vdc

• Analog Voltage Range (V_DD – V_EE) = 3.0 to 18 V

Note: V_EE must be V_SS

• Linearized Transfer Characteristics

• Low Noise — 12 nV√Cycle, f ≥ 1.0 kHz typical

• For Low R_ON, Use The HC4051, HC4052, or HC4053 High–Speed CMOS Devices

• Switch Function is Break Before Make

MAXIMUM RATING⁽¹⁾

Symbol	Parameter	Value	Unit
V_DD	DC Supply Voltage Range (Referenced to V_EE, V_SS ≥ V_EE)	– 0.5 to + 18.0	V
Vin, Vout	Input or Output Voltage (DC or Transient) (Referenced to V_SS for Control Input & V_EE for Switch I/O)	– 0.5 to V_DD + 0.5	V
Iin	Input Current (DC or Transient), per Control Pin	± 10	mA
Isw	Switch Through Current	± 25	mA
P_D	Power Dissipation, per Package⁽²⁾	500	mW
T_A	Ambient Temperature Range	– 55 to + 125	℃
Tstg	Storage Temperature Range	– 65 to + 150	℃
T_L	Lead Temperature (8–Second Soldering)	260	℃

1. Maximum Ratings are those values beyond which damage to the device may occur.

2. Temperature Derating: Plastic “P and D/DW” Packages: – 7.0 mW/C From 65C To 125C
