KA7915TU Electronic IC Chips 3 - Terminal 1A Negative Voltage Regulator

: Large Image : KA7915TU Electronic IC Chips 3 - Terminal 1A Negative Voltage Regulator

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	KA7915TU

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	7100pcs

Contact Now

Detailed Product Description

Output Voltage:	-5.0 V	Quiescent Current:	3 MA
Temperature Coefficient Of VD:	-0.4 MV/°C	Output Noise Voltage:	40 μV
Ripple Rejection:	60 DB	Dropout Voltage:	2 V
Short Circuit Current:	300 MA	Peak Current:	2.2 A
High Light:	electronic integrated circuit , linear integrated circuits

KA7915TU Electronic IC Chips 3 - Terminal 1A Negative Voltage Regulator

Features

• Output Current in Excess of 1A

• Output Voltages of -5, -6, -8, -9, -12, -15, -18 , -24V

• Internal Thermal Overload Protection

• Short Circuit Protection

• Output Transistor Safe Operating Area Compensation

Description

The KA79XX/KA79XXA series of three-terminal negative regulators are available in TO-220 package and with several fixed output voltages, making them useful in a wide range of applications. Each type employs internal current limiting, thermal shutdown and safe operating area protection, making it essentially indestructible.

Absolute Maximum Ratings

Parameter	Symbol	Value	Unit
Input Voltage	V_I	-35	V
Thermal Resistance Junction-Case (Note1)	R_θJC	5	°C/W
Thermal Resistance Junction-Air (Note1, 2)	R_θJA	65	°C/W
Operating Temperature Range	T_OPR	0 ~ +125	°C
Storage Temperature Range	T_STG	- 65 ~ +150	°C

Note:

1. Thermal resistance test board Size: 76.2mm * 114.3mm * 1.6mm(1S0P) JEDEC standard: JESD51-3, JESD51-7

2. Assume no ambient airflow

KA7915TU Electronic IC Chips 3 - Terminal 1A Negative Voltage Regulator

Internal Block Digram

KA7915TU Electronic IC Chips 3 - Terminal 1A Negative Voltage Regulator
