OCTAL D-TYPE LATCH WITH 3 STATE OUTPUT HC373 NON INVERTING - HC533 INVERTING

FEATURES:
HIGH SPEED tPD = 11 ns (TYP.) AT VCC =5V .
LOW POWER DISSIPATION ICC = 4 µA (MAX.) AT TA = 25 °C .
HIGH NOISE IMMUNITY VNIH = VNIL = 28 % VCC (MIN.) .
OUTPUT DRIVE CAPABILITY 15 LSTTL LOADS .
SYMMETRICAL OUTPUT IMPEDANCE IOL = IOH= 6 mA (MIN.) .
BALANCED PROPAGATION DELAYS tPLH = tPHL .
WIDE OPERATING VOLTAGE RANGE VCC (OPR) = 2 V TO 6 V .
PIN AND FUNCTION COMPATIBLE WITH 54/74LS373/533

General Description
           The M54/74HC373/533 are high speed CMOS OCTAL LATCH WITH 3-STATE OUTPUTS fabricated with in silicon gate C2 MOS technology. These ICs achive the high speed operation similar to equivalent LSTTL while maintaning the CMOS low power dissipation.

          These 8 bit D-Type latches are controlled by a latch enable input (LE) and a output enable input (OE). While the LE input is held at a high level, the Q outputs will follow the data input precisely or inversely.

          When the LE is taken low, the Q outputs will be latched precisely or inversely at the logic level of D input data. While the OE input is at low level, the eight outputs will be in a normal logic state (high or low logic level) and while high level the outpts will be in a high impedance state.

          The application designer has a choise of combination of inverting and non inverting outputs. The three state output configuration and the wide choise of outline make bus organized system simple. All inputs are equipped with protection circuits against discharge and transient excess voltage.
ABSOLUTE MAXIMUM RATINGS(1)
