TS5A3160
1-Ω SPDT ANALOG SWITCH
5-V/3.3-V SINGLE-CHANNEL 2:1 MULTIPLEXER/DEMULTIPLEXER
FEATURES
APPLICATIONS
DESCRIPTION
The TS5A3160 is a single-pole double-throw (SPDT) analog switch that is designed to operate from 1.65 V to 5.5 V. The device offers a low ON-state resistance and an excellent channel-to-channel ON-state resistance matching. The device has excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio applications.
ABSOLUTE MINIMUM AND MAXIMUM RATINGS(1)(2)
over operating free-air temperature range (unless otherwise noted)
MIN | MAX | UNIT | |||
V+ | Supply voltage range(3) | –0.5 | 6.5 | V | |
VNC VNO VCOM |
Analog voltage range(3)(4)(5) | –0.5 | V+ + 0.5 | V | |
IK | Analog port diode current | VNC, VNO, VCOM < 0 | –50 | mA | |
INC INO ICOM |
On-state switch current | –200 | 200 | mA | |
On-state peak switch current (6) | VNC, VNO, VCOM = 0 to V+ | –400 | 400 | mA | |
VI | Digital input voltage range(3)(4) | –0.5 | 6.5 | V | |
IIK | Digital input clamp current | VI < 0 | –50 | mA | |
I+ | Continuous current through V+ | 100 | mA | ||
IGND | Continuous current through GND | -100 | mA | ||
θJA | Package thermal impedance(7) | DBV package | 165 | °C/W | |
DCK package | 259 | °C/W | |||
Tstg | Storage temperature range | –65 | 150 | °C |
(1) Stresses beyond those listed under "absolute maximum ratings" may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated under "recommended operating conditions" is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) The algebraic convention, whereby the most negative value is a minimum and the most positive value is a maximum
(3) All voltages are with respect to ground, unless otherwise specified.
(4) The input and output voltage ratings may be exceeded if the input and output clamp-current ratings are observed.
(5) This value is limited to 5.5 V maximum.
(6) Pulse at 1-ms duration < 10% duty cycle
(7) The package thermal impedance is calculated in accordance with JESD 51-7.
