SFH756V Electronics Components rj45 female connector

: Large Image : SFH756V Electronics Components rj45 female connector

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	SFH756V

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	7500pcs

Contact Now

Detailed Product Description

Operating Temperature:	–40 To +85 °C	Storage Temperature:	–40 To +100 °C
Junction Temperature:	100 °C	Soldering Temperature:	260 °C
Reverse Voltage:	3 V	Forward Current:	50 MA
Highlight:	chip in electronics , small scale integrated circuits

Plastic Fiber Optic Transmitter Diode Plastic Connector Housing SFH756V

Features

• 2.2 mm Aperture holds Standard 1000 Micron Plastic Fiber

• No Fiber Stripping Required

• Good Linearity (Forward current > 2 mA)

• Molded Microlens for Efficient Coupling

Plastic Connector Housing

• Mounting Screw Attached to the Connector

• Interference Free Transmission from light-Tight Housing

• Transmitter and Receiver can be flexibly positioned

• No Cross Talk

• Auto insertable and Wave solderable

• Supplied in Tubes

Applications

• Household Electronics

• Power Electronics

• Optical Networks

• Light Barriers

Absolute Maximum Ratings

Parameter	Symbol	Limit Values		Unit
Parameter	Symbol	min.	max.	Unit
Operating Temperature Range	T_OP	–40	+85	°C
Storage Temperature Range	T_STG	–40	+100	°C
Junction Temperature	T_J		100	°C
Soldering Temperature (2 mm from case bottom, t ≤ 5 s)	T_S		260	°C
Reverse Voltage	V_R		3	V
Forward Current	I_F		50	mA
Surge Current (t ≤ 10 µs, D = 0)	I_FSM		1	A
Power Dissipation	P_TOT		120	mW
Thermal Resistance, Junction/Air	R_thJA		450	K/W

SFH756V Electronics Components rj45 female connector

Package Outlines

SFH756V Electronics Components rj45 female connector
