R1LP0108E Series
1Mb Advanced LPSRAM (128k word x 8bit)
Description
The R1LP0108E Series is a family of low voltage 1-Mbit static RAMs organized as 131,072-word by 8-bit, fabricated by Renesas’s high-performance 0.15um CMOS and TFT technologies. The R1LP0108E Series has realized higher density, higher performance and low power consumption. The R1LP0108E Series is suitable for memory applications where a simple interfacing, battery operating and battery backup are the important design objectives. It has been packaged in 32-pin SOP,32-pin TSOP and 32-pin sTSOP.
Features
• Single 4.5~5.5V power supply
• Small stand-by current: 1µA (5.0V, typical)
• No clocks, No refresh
• All inputs and outputs are TTL compatible.
• Easy memory expansion by CS1# and CS2
• Common Data I/O
• Three-state outputs: OR-tie Capability
• OE# prevents data contention on the I/O bus
Absolute Maximum
Parameter | Symbol | Value | unit | |
Power supply voltage relative to Vss | Vcc | -0.3 to +7 | V | |
Terminal voltage on any pin relative to Vss | VT | -0.3*1 to Vcc+0.3*2 | V | |
Power dissipation | ||||
Operation temperature | Topr*3 | R Ver. | 0 to +70 | °C |
I Ver. | -40 to +85 | |||
Storage temperature range | Tstg | -65 to 150 | °C | |
Storage temperature range under bias | Tbias*3 | R Ver. | 0 to +70 | °C |
I Ver. | -40 to +85 |
Note 1. –3.0V for pulse ≤ 30ns (full width at half maximum)
2. Maximum voltage is +7V.
3. Ambient temperature range depends on R/I-version. Please see table on page 1.
Block Diagram
