MCP6S26-I/SL Electronic IC Chips Single-Ended, Rail-to-Rail I/O

MCP6S21/2/6/8

Single-Ended, Rail-to-Rail I/O, Low Gain PGA

Features

• Multiplexed Inputs: 1, 2, 6 or 8 channels

• 8 Gain Selections:

  - +1, +2, +4, +5, +8, +10, +16 or +32 V/V

• Serial Peripheral Interface (SPI)

• Rail-to-Rail Input and Output

• Low Gain Error: ±1% (max)

• Low Offset: ±275 µV (max)

• High Bandwidth: 2 to 12 MHz (typ)

• Low Noise: 10 nV/Hz @ 10 kHz (typ)

• Low Supply Current: 1.0 mA (typ)

• Single Supply: 2.5V to 5.5V

Typical Applications

• A/D Converter Driver

• Multiplexed Analog Applications

• Data Acquisition

• Industrial Instrumentation

• Test Equipment

• Medical Instrumentation

Description

The Microchip Technology Inc. MCP6S21/2/6/8 are analog Programmable Gain Amplifiers (PGA). They can be configured for gains from +1 V/V to +32 V/V and the input multiplexer can select one of up to eight channels through an SPI port. The serial interface can also put the PGA into shutdown to conserve power. These PGAs are optimized for high speed, low offset voltage and single-supply operation with rail-to-rail input and output capability. These specifications support single supply applications needing flexible performance or multiple inputs.

The one channel MCP6S21 and the two channel MCP6S22 are available in 8-pin PDIP, SOIC and MSOP packages. The six channel MCP6S26 is available in 14-pin PDIP, SOIC and TSSOP packages. The eight channel MCP6S28 is available in 16-pin PDIP and SOIC packages. All parts are fully specified from -40°C to +85°C.

Absolute Maximum Ratings †

V_DD - V_SS .........................................................................7.0V

All inputs and outputs....................... V_SS - 0.3V to V_DD +0.3V

Difference Input voltage ........................................ |V_DD - V_SS|

Output Short Circuit Current...................................continuous

Current at Input Pin .......................................................±2 mA

Current at Output and Supply Pins ..............................±30 mA

Storage temperature .....................................-65°C to +150°C

Junction temperature .................................................. +150°C

ESD protection on all pins (HBM;MM) ....................≥2 kV; 200V

† Notice: Stresses above those listed under "Maximum Ratings" may cause permanent damage to the device. This is a stress rating only and functional operation of the device at those or any other conditions above those indicated in the operation listings of this specification is not implied. Exposure to maximum rating conditions for extended periods may affect device reliability.

Block Diagram

Package Types
