CD4052BM Electronic IC Chips CMOS Analog Multiplexers / Demultiplexers

CD4051B, CD4052B, CD4053B

CMOS Analog Multiplexers/Demultiplexers with Logic Level Conversion

Features

• Wide Range of Digital and Analog Signal Levels

  - Digital . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3V to 20V

  - Analog. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤20V_P-P

• Low ON Resistance, 125Ω (Typ) Over 15V_P-P Signal Input Range for V_DD-V_EE = 18V

• High OFF Resistance, Channel Leakage of ±100pA (Typ) at V_DD-V_EE = 18V

• Logic-Level Conversion for Digital Addressing Signals of 3V to 20V (V_DD-V_SS = 3V to 20V) to Switch Analog Signals to 20VP-P (V_DD-V_EE = 20V)

• Matched Switch Characteristics, r_ON = 5Ω (Typ) for V_DD-V_EE = 15V

• Very Low Quiescent Power Dissipation Under All DigitalControl Input and Supply Conditions, 0.2µW (Typ) at V_DD-V_SS = V_DD-V_EE = 10V

• Binary Address Decoding on Chip

• 5V, 10V, and 15V Parametric Ratings

• 100% Tested for Quiescent Current at 20V

• Maximum Input Current of 1µA at 18V Over Full Package Temperature Range, 100nA at 18V and 25℃

• Break-Before-Make Switching Eliminates Channel Overlap

Applications

• Analog and Digital Multiplexing and Demultiplexing

• A/D and D/A Conversion

• Signal Gating

CMOS Analog Multiplexers/Demultiplexers with Logic Level Conversion

The CD4051B, CD4052B, and CD4053B analog multiplexers are digitally-controlled analog switches having low ON impedance and very low OFF leakage current. Control of analog signals up to 20V_P-P can be achieved by digital signal amplitudes of 4.5V to 20V (if V_DD-V_SS = 3V, a V_DD-V_EE of up to 13V can be controlled; for V_DD-V_EE level differences above 13V, a V_DD-V_SS of at least 4.5V is required). For example, if V_DD = +4.5V, V_SS = 0V, and V_EE = -13.5V, analog signals from -13.5V to +4.5V can be controlled by digital inputs of 0V to 5V.

These multiplexer circuits dissipate extremely low quiescent power over the full V_DD-V_SS and V_DD-V_EE supply-voltage ranges, independent of the logic state of the control signals. When a logic “1” is present at the inhibit input terminal, all channels are off.

The CD4051B is a single 8-Channel multiplexer having three binary control inputs, A, B, and C, and an inhibit input. The three binary signals select 1 of 8 channels to be turned on, and connect one of the 8 inputs to the output.

The CD4052B is a differential 4-Channel multiplexer having two binary control inputs, A and B, and an inhibit input. The two binary input signals select 1 of 4 pairs of channels to be turned on and connect the analog inputs to the outputs.

The CD4053B is a triple 2-Channel multiplexer having three separate digital control inputs, A, B, and C, and an inhibit input. Each control input selects one of a pair of channels which are connected in a single-pole, double-throw configuration.

When these devices are used as demultiplexers, the “CHANNEL IN/OUT” terminals are the outputs and the “COMMON OUT/IN” terminals are the inputs.

Absolute Maximum Ratings

Supply Voltage (V+ to V-)

    Voltages Referenced to VSS Terminal . . . . . . . . . . . -0.5V to 20V

DC Input Voltage Range . . . . . . . . . . . . . . . . . . -0.5V to VDD +0.5V

DC Input Current, Any One Input. . . . . . . . . . . . . . . . . . . . . . ±10mA

Thermal Information

Package Thermal Impedance, θ_JA (see Note 1):

   E (PDIP) package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67℃/W

   M (SOIC) package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73℃/W

   NS (SOP) package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64℃/W

   PW (TSSOP) package . . . . . . . . . . . . . . . . . . . . . . . . . . 108℃/W

Maximum Junction Temperature (Ceramic Package) . . . . . . . .175℃

Maximum Junction Temperature (Plastic Package) . . . . . . . .150℃

Maximum Storage Temperature Range. . . . . . . . . . -65℃ to 150℃

Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . 265℃

   (SOIC - Lead Tips Only)

CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied.

NOTE: 1. The package thermal impedance is calculated in accordance with JESD 51-7.

Pinouts
