NJM2068D integrated circuits ics LOW NOISE DUAL OPERATIONAL AMPLIFIER

: Large Image : NJM2068D integrated circuits ics LOW NOISE DUAL OPERATIONAL AMPLIFIER

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	NJM2068D

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	7800pcs

Contact Now

Detailed Product Description

Supply Voltage:	±18 V	Differential Input Voltage:	±30 V
Common Mode Input Voltage:	±15 V	Operating Temperature:	-20~+75 ºC
Storage Temperature:	-40~+125 ºC	Supply Current:	5 MA
High Light:	electronic integrated circuit , linear integrated circuits

Stock Offer (Hot Sell)

Part No.

Quantity

Brand

D/C

Package

PGB2010402KRHF	146000	LITTEIFUS	16+	SMD0402
PHC21025	12000	NXP	16+	SOP-8
PI3B3257QEX	13759	PERICOM	15+	SSOP-16
PI5V330QEX	32000	PERICOM	06+	SSOP-16
PI7C8150BMAE	3988	PERICOM	15+	QFP208
PI90LV01TEX	6162	PERICOM	08+	SOT23-5
PIC10F220-I/P	7118	MICROCHIP	10+	DIP-8
PIC10F320T-I/OT	5427	MICROCHIP	16+	SOT23-6
PIC12F1501T-I/MS	5262	MICROCHIP	14+	MSOP-8
PIC12F1822-I/P	17379	MICROCHIP	14+	DIP-8
PIC12F615-I/MS	5489	MICROCHIP	16+	MSOP-8
PIC12F629-I/P	8713	MICROCHIP	16+	DIP-8
PIC12F675-I/SN	4363	MICROCHIP	14+	SOP-8
PIC16C56A-04/P	5700	MICROCHIP	16+	DIP-18
PIC16C72A-04/SP	5160	MICROCHIP	07+	DIP-28
PIC16F1503-I/ST	4595	MICROCHIP	14+	TSSOP-14
PIC16F1823-I/SL	6596	MICROCHIP	16+	SOP-14
PIC16F1829-I/SS	2033	MICROCHIP	16+	SSOP-20
PIC16F1934-I/PT	4242	MICROCHIP	13+	TQFP-44
PIC16F1936-I/SS	12473	MICROCHIP	16+	SSOP-28
PIC16F1937-I/PT	4113	MICROCHIP	15+	QFP44
PIC16F1947-I/PT	6997	MICROCHIP	15+	QFP64
PIC16F506-I/ST	6567	MICROCHIP	08+	TSSOP-14
PIC16F616-I/P	16463	MICROCHIP	16+	DIP-14
PIC16F630-I/P	3914	MICROCHIP	16+	DIP-14
PIC16F636-I/SL	12189	MICROCHIP	15+	SOP-14
PIC16F648A-I/SO	3995	MICROCHIP	15+	SOP-18
PIC16F648A-I/SS	4066	MICROCHIP	10+	SSOP-20
PIC16F676-I/P	9917	MICROCHIP	15+	DIP-14
PIC16F676-I/SL	4940	MICROCHIP	15+	SOP-14

NJM2068

LOW-NOISE DUAL OPERATIONAL AMPLIFIER

GENERAL DESCRIPTION

The NJM2068 is a high performance, low noise dual operational amplifier. This amplifier features popular pin-out, superior noise performance, and superior total harmonic distortion. This amplifier also features guaranteed noise performance with substantially higher gain-bandwidth product and slew rate, which far exceeds that of the 4558 type amplifier.

The specially designed low noise input transistors allow the NJM2068 to be used in very low noise signal processing applications such as audio preamplifiers and servo error amplifier.

The D-Rank type products(NJM2068DD/LD/MD) have specified maximum limits for equivalent input noise voltage.

FEATURES

● Operating Voltage ±4V~±18V

● Low Total Harmonic Distortion 0.001%

● Low Noise Voltage 0.56µV (FLAT+JISA)

● High Slew Rate 6V/µs

● Unity Gain Bandwidth 27MHz (f=10kHz)

● Bipolar Technology

● Package Outline DIP8, DMP8, SIP8, SSOP8

ABSOLUTE MAXIMUM RATINGS(Ta=25°C)

PARAMETER	SYMBOL	RATING	UNIT
Supply Voltage	V+ /V-	±18	V
Differential Input Voltage Range	V_ID	±30	V
Common Mode Input Voltage Range	V_IC	±15 (Note1)	V
Power Dissipation	P_D	DIP8: 500 DMP8: 300 SSOP8: 250 SIP8: 800	mW
Operating Temperature Range	T_opr	-20~+75	ºC
Storage Temperature Range	T_stg	-40~+125	ºC
