TDA8571J 4 x 40 W BTL quad car radio power amplifier ic chip , integrated components

Stock Offer (Hot Sell)

TDA8571J

4 x 40 W BTL quad car radio power amplifier

FEATURES

• Requires very few external components

• High output power

• Low output offset voltage

• Fixed gain

• Diagnostic facility (distortion, short-circuit and temperature pre-warning)

• Good ripple rejection

• Mode select switch (operating, mute and standby)

• Load dump protection

• Short-circuit safe to ground and to VP and across the load

• Low power dissipation in any short-circuit condition

• Thermally protected

• Reverse polarity safe

• Electrostatic discharge protection

• No switch-on/switch-off plop

• Flexible leads

• Low thermal resistance

• Pin compatible with the TDA8568Q, except for the gain.

GENERAL DESCRIPTION

The TDA8571J is a integrated class-B output amplifier contained in a 23-lead Single-In-Line (SIL) plastic power package. It contains four amplifiers in a BTL configuration, each with a gain of 34 dB. The output power is 4 × 40 W (EIAJ) into a 4 Ω load.

APPLICATIONS

• The device is primarily developed for car radio applications.

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

PACKAGE OUTLINE

DBS23P: plastic DIL-bent-SIL power package; 23 leads (straight lead length 3.2 mm) SOT411-1
