Product Details:
Payment & Shipping Terms:
|
| DC Supply Voltage (Pins 4,7,12,15): | 60 V | Maximum Voltage On Pins 23 To 32: | 5.5 V |
|---|---|---|---|
| Operating Temperature: | 0 To 70 °C | Storage And Junction Temperature: | -40 To 150 °C |
| Supply Operating Voltage: | 10 To 52 V | Thermal Warning Temperature: | 130 °C |
| Thermal Shut-down Junction Temperature: | 150 °C | Thermal Shut-down Hysteresis: | 25 °C |
| High Light: | electronic integrated circuit,linear integrated circuits |
||
Stock Offer (Hot Sell)
| Part No. | Quantity | Brand | D/C | Package |
| LT1933ES6 | 2520 | LT | 16+ | SOT23-6 |
| LT1963AEQ-3.3 | 4329 | LINEAR | 15+ | TO-263 |
| LT3008ETS8 | 18224 | LT | 16+ | SOT23-8 |
| LT3086EFE | 4480 | LT | 16+ | TSSOP |
| LT3494EDDB | 6707 | LINEAR | 15+ | DFN-8 |
| LT4363IMS-2 | 3550 | LINEAR | 14+ | MSOP |
| LT5534ESC6#TRPBF | 3101 | LINEAR | 15+ | SC70-6 |
| LT6100IMS8 | 6678 | LINEAR | 16+ | MSOP-8 |
| LT6108IMS8-2 | 5119 | LT | 16+ | MSOP-8 |
| LTC1452IS8#TRPBF | 1457 | LINEAR | 10+ | SOIC |
| LTC1535CSW | 3037 | LT | 10+ | SOP-28 |
| LTC1545CG | 1704 | LINEAR | 00+ | SSOP-36 |
| LTC1546CG | 2661 | LINEAR | 04+ | SSOP |
| LTC1877EMS8#PBF | 1638 | LT | 15+ | MSOP-8 |
| LTC2050CS5#TR | 15318 | LINEAR | 01+ | SOT23-5 |
| LTC2924IGN | 3108 | LT | 16+ | SSOP-16 |
| LTC2955ITS8-2 | 1861 | LINEAR | 16+ | SOT23-8 |
| LTC3112EDHD | 3059 | LT | 16+ | QFN16 |
| LTC3371EUHF#PBF | 2317 | LINEAR | 14+ | QFN |
| LTC3406ES5-1.5#TRPBF | 9278 | LINEAR | 10+ | SOT23-5 |
| LTC3454EDD | 3010 | LT | 13+ | DFN-10 |
| LTC3545EUD-1#TRPBF | 2652 | LINEAR | 13+ | QFN16 |
| LTC3621EMS8E | 3150 | LINEAR | 13+ | MSOP-8 |
| LTC3631IMS8E | 2803 | LT | 16+ | MSOP-8 |
| LTC3789EUFD | 2385 | LINEAR | 16+ | QFN |
| LTC3850EGN#TRPBF | 18295 | LINEAR | 13+ | SSOP-28 |
| LTC3850EUF | 7490 | LINEAR | 15+ | QFN |
| LTC3851EGN | 3121 | LINEAR | 15+ | SSOP |
| LTC4011CFE | 4687 | LINEAR | 08+ | TSSOP-20 |
| LTC4054ES5-4.2 | 6539 | LT | 16+ | SOT23-5 |
STA516B
60 V 6 A quad power half bridge
Features
■ Minimum input output pulse width distortion
■ 200 mΩ RdsON complementary DMOS output stage
■ CMOS compatible logic inputs
■ Thermal protection
■ Thermal warning output
■ Under voltage protection
Description
STA516B is a monolithic quad half bridge stage in Multipower BCD Technology. The device can be used as dual bridge or reconfigured, by connecting CONFIG pin to Vdd pin, as single bridge with double current capability, and as half bridge (Binary mode) with half current capability.
The device is particularly designed to make the output stage of a stereo all-digital high efficiency (DDX™) amplifier capable to deliver 160 + 160 W @ THD = 10 % at Vcc 50 V output power on 8 Ω load and 320 W @ THD = 10 % at Vcc 50V on 4 Ω load in single BTL configuration.
The input pins have threshold proportional to VL pin voltage.
Absolute maximum ratings
| Symbol | Parameter | Value | Unit |
| VCC | DC supply voltage (Pins 4,7,12,15) | 60 | V |
| Vmax | Maximum voltage on pins 23 to 32 | 5.5 | V |
| Top | Operating temperature range | 0 to 70 | °C |
| Tstg, Tj | Storage and junction temperature | -40 to 150 | °C |
