Product Details:
Payment & Shipping Terms:
|
Total Analog Supply Voltage: | . +14 V | Digital Supply Voltage: | . +14 V |
---|---|---|---|
Analog Positive Supply–Digital Positive Supply: | –600 MV | Input Voltage1: | ±7 V |
Differential Input Voltage: | ±8 V | ||
High Light: | electronic integrated circuit,linear integrated circuits |
FEATURES
7 ns Propagation Delay at 5 V
Single Supply Operation: 3 V to 10 V
Low Power Latch Function
TSSOP Packages
APPLICATIONS
High Speed Timing
Clock Recovery and Clock Distribution
Line Receivers
Digital Communications
Phase Detectors
High Speed Sampling
Read Channel Detection
PCMCIA Cards
Upgrade for LT1016 Designs
GENERAL DESCRIPTION
The AD8561 is a single 7 ns comparator with separate input and output sections. Separate supplies enable the input stage to be operated from ±5 V dual supplies and +5 V single supplies
Fast 7 ns propagation delay makes the AD8561 a good choice for timing circuits and line receivers. Propagation delays for rising and falling signals are closely matched and track over temperature. This matched delay makes the AD8561 a good choice for clock recovery, since the duty cycle of the output will match the duty cycle of the input.
The AD8561 has the same pinout as the LT1016, with lower supply current and a wider common-mode input range, which includes the negative supply rail
The AD8561 is specified over the industrial (–40°C to +85°C) temperature range. The AD8561 is available in both the 8-lead plastic DIP, 8-lead TSSOP or narrow SO-8 surface mount packages.
