Product Details:
Payment & Shipping Terms:
|
Average Ramp-up Rate (217°C To Peak): | 3° C/sec. Max | Preheat Temperature 175°C ±25°C: | 180 Sec. Max. |
---|---|---|---|
Temperature Maintained Above 217°C: | 60 Sec. To 150 Sec | Time Within 5° C Of Actual Peak Temperature: | 20 Sec. To 40 Sec. |
Peak Temperature Range: | 260° C | ||
High Light: | electronic integrated circuit,linear integrated circuits |
The AT91M40800 microcontroller is a member of the Atmel AT91 16/32-bit microcontroller family, which is based on the ARM7TDMI processor core. This processor has a high-performance 32-bit RISC architecture with a high-density 16-bit instruction set and very low power consumption. In addition, a large number of internally banked registers result in very fast exception handling, making the device ideal for real-time control applications.
The AT91M40800 microcontroller features a direct connection to off-chip memory, including Flash, through the fully-programmable External Bus Interface (EBI). An eight-level priority vectored interrupt controller, in conjunction with the Peripheral Data Controller, significantly improves the real-time performance of the device.
The device is manufactured using Atmel’s high-density CMOS technology. By combining the ARM7TDMI processor core with on-chip high-speed memory and a wide range of peripheral functions on a monolithic chip, the AT91M40800 is a powerful microcontroller that offers a flexible, cost-effective solution to many compute-intensive embedded control applications.
Soldering Profile Green Compliant Package
Profile Feature | Green Package |
Average Ramp-up Rate (217°C to Peak) | 3° C/sec. max |
Preheat Temperature 175°C ±25°C | 180 sec. max |
Temperature Maintained Above 217°C | 60 sec. to 150 sec. |
Time within 5° C of Actual Peak Temperature | 20 sec. to 40 sec |
Peak Temperature Range | 260° C |
Ramp-down Rate | 6° C/sec. max |
Time 25° C to Peak Temperature | 8 min. max |
