AD8002AR Electronic IC Chips 50 mW Current Feedback Amplifier

Dual 600 MHz, 50 mW Current Feedback Amplifier AD8002

FEATURES

Excellent Video Specifications (RL = 150 , G = +2)

  Gain Flatness 0.1 dB to 60 MHz

  0.01% Differential Gain Error

  0.02% Differential Phase Error

Low Power

  5.5 mA/Amp Max Power Supply Current (55 mW)

High Speed and Fast Settling

  600 MHz, –3 dB Bandwidth (G = +1)

  500 MHz, –3 dB Bandwidth (G = +2)

  1200 V/s Slew Rate

  16 ns Settling Time to 0.1%

Low Distortion

  –65 dBc THD, fC = 5 MHz

  33 dBm Third Order Intercept, F1 = 10 MHz

  –66 dB SFDR, f = 5 MHz

  –60 dB Crosstalk, f = 5 MHz

High Output Drive

  Over 70 mA Output Current

  Drives Up to Eight Back-Terminated 75 Loads

    (Four Loads/Side) While Maintaining Good

    Differential Gain/Phase Performance (0.01%/0.17)

Available in 8-Lead Plastic DIP, SOIC and μSOIC Packages

APPLICATIONS

A-to-D Driver

Video Line Driver

Differential Line Driver

Professional Cameras

Video Switchers

Special Effects

RF Receivers

PRODUCT DESCRIPTION

The AD8002 is a dual, low-power, high-speed amplifier designed to operate on ±5 V supplies. The AD8002 features unique transimpedance linearization circuitry. This allows it to drive video loads with excellent differential gain and phase performance on only 50 mW of power per amplifier.

The AD8002 is a current feedback amplifier and features gain flatness of 0.1 dB to 60 MHz while offering differential gain and phase error of 0.01% and 0.02°. This makes the AD8002 ideal for professional video electronics such as cameras and video switchers. Additionally, the AD8002’s low distortion and fast settling make it ideal for buffer high-speed A-to-D converters.

The AD8002 offers low power of 5.5 mA/amplifier max (VS = ±5 V) and can run on a single 12 V power supply, while capable of delivering over 70 mA of load current. It is offered in an 8-lead plastic DIP, SOIC, and µSOIC package. These features make this amplifier ideal for portable and battery-powered applications where size and power are critical.

The outstanding bandwidth of 600 MHz along with 1200 V/µs of slew rate make the AD8002 useful in many general purpose high speed applications where dual power supplies of up to ±6 V and single supplies from 6 V to 12 V are needed. The AD8002 is available in the industrial temperature range of –40°C to +85°C.

ABSOLUTE MAXIMUM RATINGS¹

Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.2 V

Internal Power Dissipation²

    Plastic DIP Package (N)  . . . . . . . . . . . . . . . . . . . . . . . 1.3 W

    Small Outline Package (R) . . . . . . . . . . . . . . . . . . . . . . 0.9 W

    µSOIC Package (RM) . . . . . . . . . . . . . . . . . . . . . . . . . 0.6 W

Input Voltage (Common Mode) . . . . . . . . . . . . . . . . . . . . ±VS

Differential Input Voltage . . . . . . . . . . . . . . . . . . . . . . . ±1.2 V

Output Short Circuit Duration . . . . . . . . . . . . . . . . . . . . . . Observe Power Derating Curves

Storage Temperature Range N, R, RM . . . . . –65°C to +125°C

Operating Temperature Range (A Grade) . . . –40°C to +85°C

Lead Temperature Range (Soldering 10 sec) . . . . . . . . . 300°C

NOTES

1 Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

2 Specification is for device in free air:

   8-Lead Plastic DIP Package: θ_JA = 90°C/W

   8-Lead SOIC Package: θ_JA = 155°C/W

   8-Lead µSOIC Package: θ_JA = 200°C/W

FUNCTIONAL BLOCK DIAGRAM

8-Lead Plastic DIP, SOIC, and μSOIC
