Product Details:
Payment & Shipping Terms:
|
| Collector-Emitter Voltage: | 40 V | Collector-Base Voltage: | 60 V |
|---|---|---|---|
| Emitter-Base Voltage: | 6.0 V | Collector Current - Continuous: | 600 MA |
| Operating Junction Temperature: | -55 To +150 °C | Storage Temperature: | -55 To +150 °C |
| Highlight: | electronic integrated circuit,linear integrated circuits |
||
NPN General Pupose Amplifier
This device is designed for use as a medium power amplifier and switch requiring collector currents up to 500 mA.
Absolute Maximum Ratings* TA = 25°C unless otherwise noted
| Symbol | Parameter | Value | Units |
| VCEO | Collector-Emitter Voltage | 40 | V |
| VCBO | Collector-Base Voltage | 60 | V |
| VEBO | Emitter-Base Voltage | 6.0 | V |
| IC | Collector Current - Continuous | 600 | mA |
| TJ, Tstg | Operating and Storage Junction Temperature Range | -55 to +150 | °C |
*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
NOTES:
1) These ratings are based on a maximum junction temperature of 150 degrees C.
2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.
2N4401 MMBT4401
Test Circuits
FIGURE 1: Saturated Turn-On Switching Timer
FIGURE 2: Saturated Turn-Off Switching Time
