Product Details:
Payment & Shipping Terms:
|
| Operating Frequency: | DC - 20 MHz | Resets (and Delays): | POR, BOR (PWRT, OST) |
|---|---|---|---|
| FLASH Program Memory (14-bit Words): | 8K | Data Memory (bytes): | 368 |
| EEPROM Data Memory: | 256 | ||
| High Light: | electronic integrated circuit,linear integrated circuits |
||
DEVICE OVERVIEW
This document contains device specific information for the following devices:
PIC18F242
• PIC18F442
• PIC18F252
• PIC18F452
These devices come in 28-pin and 40/44-pin packages. The 28-pin devices do not have a Parallel Slave Port (PSP) implemented and the number of Analog-toDigital (A/D) converter input channels is reduced to 5. An overview of features is shown in Table 1-1.
The following two figures are device block diagrams sorted by pin count: 28-pin for Figure 1-1 and 40/44-pin for Figure 1-2. The 28-pin and 40/44-pin pinouts are listed in Table 1-2 and Table 1-3, respectively.
Microcontroller Core Features:
• High-performance RISC CPU
• Only 35 single word instructions to learn
• All single cycle instructions except for program branches which are two cycle
• Operating speed:
DC - 20 MHz clock input
DC - 200 ns instruction cycle
• Up to 8K x 14 words of FLASH Program Memory, Up to 368 x 8 bytes of Data Memory (RAM) Up to 256 x 8 bytes of EEPROM data memory
• Pinout compatible to the PIC16C73B/74B/76/77
• Interrupt capability (up to 14 sources)
• Eight level deep hardware stack
• Direct, indirect and relative addressing modes
