UCC28610D Electronic IC Chips GREEN-MODE FLYBACK CONTROLLER

: Large Image : UCC28610D Electronic IC Chips GREEN-MODE FLYBACK CONTROLLER

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	UCC28610D

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8200pcs

Contact Now

Detailed Product Description

Continuous Input Current:	10 MA	Input Current Range:	–3 To +1 MA
Operating Junction Temperature:	–40 To +150°C	Storage Temperature:	–65 To +150°C
Lead Temperature (soldering, 10 Sec.):	+260°C	Package:	SOIC-8, PDIP-8
High Light:	electronic integrated circuit , linear integrated circuits

Stock Offer (Hot Sell)

Part no.

Quantity

Brand

D/C

Package

NTF5P03T3G	4720	ON	16+	SOT-223
MX25L12805DMI-20G	885	MXIC	10+	SOP-16
OPA657NB/250	8100	TI	13+	SOT23-5
NDP6020P	15760	FAIRCHILD	16+	TO-220
LM3911N	875	NSC	15+	DIP-8
MMSZ5229B-7-F	20000	DIODES	16+	SOD-123
PIC18F1320-I/P	4683	MICROCHIP	12+	DIP
MAX9716EUA+T	10908	MAXIM	10+	MSOP
MAX3222CUP+T	10450	MAXIM	11+	TSSOP
PMBS3906	50000	NXP	14+	SOT-23
PIC18F23K20-I/SP	4663	MICROCHIP	16+	DIP
A3977SEDTR	803	ALLEGRO	13+	PLCC44
OPA656N	8040	TI	14+	SOT23-5
OPA843IDBVR	8260	TI	16+	SOT23-5
OPA820IDBVR	8240	TI	16+	SOT23-5
LM2679T-ADJ	3000	NSC	14+	TO-220-7
MPX4250DP	6078	FREESCALE	15+	DIP
30057*	310	BOSCH	10+	TO-263
30586*	424	BOSCH	10+	SOP-16
M93C46-WBN6TP	3594	ST	16+	DIP
30424*	708	BOSCH	10+	PLCC28
LTC1487CN8	15582	LT	16+	DIP
30591*	524	BOSCH	10+	QFP-64
LTV4N35	30000	LITEON	16+	DIP-6
PIC18F46K22-I/P	4358	MICROCHIP	14+	TQFP
LM2904QPWRQ1	10000	TI	14+	TSSOP-8
LT1413S8#TRPBF	9730	LT	13+	SOP-8
LM2902N	10000	NSC	14+	DIP-14
XC95144XL-7TQG144I	763	XILINX	15+	TQFP100
A3955SBT	1000	ALLEGRO	13+	DIP-16

UCC28610

GREEN-MODE FLYBACK CONTROLLER

FEATURES

• Cascoded Configuration Allows Fully Integrated Current Control Without External Sense Resistor

• Fast Start Up With Low Standby Power Achieved by Cascode Configuration

• Frequency and Peak Current Modulation for Optimum Efficiency Over Entire Operating Range

• Green-Mode (GM) Burst Switching Packets Improve No-Load Efficiency

• Advanced Overcurrent Protection Limits RMS Input and Output Currents

• Thermal Shutdown

• Timed Overload With Retry or Latch-Off Response

• Programmable Opto-Less Output Over-Voltage Protection

• Fast Latched Fault Recovery

• 8-Pin SOIC Package and 8-Pin PDIP Lead-Free Packages

APPLICATIONS

• AC/DC Adapters, 12 W to 65 W

• High Efficiency Housekeeping and Auxillary Power Supplies

• Offline Battery Chargers

• Consumer Electronics (DVD Players, Set-Top Boxes, DTV, Gaming, Printers, etc.)

DESCRIPTION

The UCC28610 brings a new level of performance and reliability to the AC/DC consumer power supply solution.

A PWM modulation algorithm varies both the switching frequency and primary current while maintaining discontinuous or transition mode operation over the entire operating range. Combined with a cascoded architecture, these innovations result in efficiency, reliability, and system cost improvements over a conventional flyback architecture.

The UCC28610 offers a predictable maximum power threshold and a timed response to an overload, allowing safe handling of surge power requirements. Overload fault response is user-programmed for retry or latch-off mode. Additional protection features include output overvoltage detection, programmable maximum on-time, and thermal shutdown.

ABSOLUTE MAXIMUM RATINGS⁽¹⁾

All voltages are with respect to GND, –40°C < TJ = T_A < 125°C, all currents are positive into and negative out of the specified terminal (unless otherwise noted)

			UCC28610	UNIT
Input voltage range		VDD	–0.5 to +25	V
		DRV, during conduction	–0.5 to +2.0
		DRV, during non-conduction	20
		VGG⁽²⁾	–0.5 to +16
		ZCD, MOT, CL ⁽³⁾	–0.5 to +7
		FB⁽³⁾	–0.5 to +1.0
		VDD – VGG	–7 to +10
Continuous input current		I_VGG⁽²⁾	10	mA
Input current range		I_ZCD, I_MOT, I_CL, I_FB ⁽³⁾	–3 to +1	mA
Peak output current		DRV	–5	A
Peak output current		DRV, pulsed 200ns, 2% duty cycle	–5 to +1.5	A
T_J	Operating junction temperature range		–40 to +150	°C
T_stg	Storage temperature range		–65 to +150
	Lead Temperature (soldering, 10 sec.)		+260

(1) These are stress ratings only. Stress beyond these limits may cause permanent damage to the device. Functional operation of the device at these or any conditions beyond those indicated under Recommended Operating Conditions is not implied. Exposure to absolute maximum rated conditions for extended periods of time may affect device reliability

(2) Voltage on VGG is internally clamped. The clamp level varies with operating conditions. In normal use, VGG is current fed with the voltage internally limited

(3) In normal use, MOT, CL, ZCD, and FB are connected to resistors to GND and internally limited in voltage swing
