TL084CN JEET-INPUT OPERTIONAL AMPLIFERS ic pc board circuit board ic ic circuit board

JFET-input operational amplifiers incorporates

►Low Power Consumption

► Wide Common-Mode and Differential Voltage Ranges

►Low Input Bias and Offset Currents

►Output Short-Circuit Protection

►Low Total Harmonic Distortion . . . 0.003% Typ

►High Input Impedance . . . JFET-Input Stage

►Latch-Up-Free Operation

►High Slew Rate . . . 13 V/µs Typ

►Common-Mode Input Voltage Range Includes VCC+

description/ordering information

The TL08x JFET-input operational amplifier family is designed to offer a wider selection than any previously developed operational amplifier family. Each of these JFET-input operational amplifiers incorporates well-matched, high-voltage JFET and bipolar transistors in a monolithic integrated circuit. The devices feature high slew rates, low input bias and offset currents, and low offset-voltage temperature coefficient. Offset adjustment and external compensation options are available within the TL08x family.

The C-suffix devices are characterized for operation from 0°C to 70°C. The I-suffix devices are characterized for operation from −40°C to 85°C. The Q-suffix devices are characterized for operation from −40°C to 125°C. The M-suffix devices are characterized for operation over the full military temperature range of −55°C to 125°C.

PARAMETER MEASUREMENT INFORMATION
