Product Details:
Payment & Shipping Terms:
|
Supply Voltage,: | 18 V | Supply Voltage, VCC–: | -18 V |
---|---|---|---|
Differential Input Voltage, VID: | ±15 V | Input Voltage, VI Any Input: | ±15 V |
Storage Temperature Range: | –65 To 150 °C | ||
High Light: | chip in electronics,small scale integrated circuits |
►Short-Circuit Protection
► Offset-Voltage Null Capability
►Large Common-Mode and Differential Voltage Ranges
►No Frequency Compensation Required
►Low Power Consumption
►No Latch-Up Designed to Be Interchangeable With
►Fairchild µA741
description
The µA741 is a general-purpose operational amplifier featuring offset-voltage null capability.
The high common-mode input voltage range and the absence of latch-up make the amplifier ideal for voltage-follower applications. The device is short-circuit protected and the internal frequency compensation ensures stability without external components. A low value potentiometer may be connected between the offset null inputs to null out the offset voltage as shown in Figure 2.
The µA741C is characterized for operation from 0°C to 70°C. The µA741I is characterized for operation from –40°C to 85°C.The µA741M is characterized for operation over the full military temperature range of –55°C to 125°C.
µA741C | µA741I | µA741M | UNIT | |
Supply voltage, VCC+ (see Note 1) | 18 | 22 | 22 | V |
Supply voltage, VCC– (see Note 1) | –18 | –22 | –22 | V |
Differential input voltage, VID (see Note 2) | ±15 | ±30 | ±30 | V |
Input voltage, VI any input (see Notes 1 and 3) | ±15 | ±15 | ±15 | V |
TYPICAL CHARACTERISTICS†
