AD1882JCPZ Original Integrated Circuit High Definition Audio SoundMAX Codec

: Large Image : AD1882JCPZ Original Integrated Circuit High Definition Audio SoundMAX Codec

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	AD1882JCPZ

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	6800pcs

Contact Now

Detailed Product Description

Digital Supply:	3.3 V	Analog Supply:	3.3 V
Input Current (Except Supply Pins):	±10.0 MA	Analog Output Pass Band:	20 Hz To 20 KHz
Ambient Temperature (Operating):	0 To +70 °C	Storage Temperature:	–65 +150 °C
High Light:	electronic integrated circuit , linear integrated circuits

AD1882JCPZ Original Integrated Circuit High Definition Audio SoundMAX Codec

FEATURES
Six 96 kHz DACs

Three independent stereo DAC pairs
Independent 8, 11.025, 16, 22.05, 32, 44.1, 48, 88.2, and 96 kHz sample rates
16-, 20-, and 24-bit PCM resolution
Selectable stereo mixer on outputs

Four 96 kHz ADCs

Two independent stereo ADC pairs
Simultaneous record of up to four channels
Independent 8, 11.025, 16, 22.05, 32, 44.1, 48, 88.2, and 96 kHz sample rates
16-, 20-, and 24-bit resolution

S/PDIF OUTPUT

Supports 44.1, 48, 88.2, and 96 kHz sample rates
16-, 20-, and 24-bit data widths; PCM and AC3 formats
Digital PCM gain control

DEDICATED AUXILIARY PINS

Stereo CD input w/GND sense
Mono out pin for internal speakers or telephony
Analog PCBeep input pin

ENHANCED FEATURES

Two stereo headphone amplifiers
Microsoft Vista Premium logo for notebook and desktop 95 dB audio outputs, 90 dB audio inputs
Internal 32-bit arithmetic for greater accuracy
Impedance and presence detection on all jack pins
Digital synthesis PCBeep
C/LFE channel swapping
Two general-purpose digital I/O (GPIO) pins
Advanced power management modes
EAPD control for internal speakers
48-lead, Pb-free LFCSP_VQ package

TEST CONDITIONS

Parameter	Test Condition
Temperature Digital Supply Analog Supply MIC_BIAS_IN (via Low-Pass Filter) Sample Rate f_S Input Signal (Frequency Sine Wave) Amplitude for THD + N Analog Output Pass Band	25°C 3.3 V 3.3 V 5.0 V 48 kHz 1008 Hz –3.0 dB Full Scale 20 Hz to 20 kHz
DAC	10 kΩ Output Load: Line Out Tests 32 Ω Output Load: Headphone Tests
ADC	0 dB Gain

Absolute Maximum Ratings

Power Supplies Min Max Units

Digital (DV_DD) –0.30 +3.65 V
Digital I/O (DV_IO) –0.30 +3.65 V
Analog (AV_DD) –0.30 +3.65 V
Input Current (Except Supply Pins)   ±10.0 mA
Analog Input Voltage (Signal Pins) –0.30 AV_DD + 0.3    V
Digital Input Voltage (Signal Pins) –0.30 DV_IO + 0.3 V
Ambient Temperature (Operating) 0 +70 °C
Storage Temperature    –65    +150 °C

AD1882 Block Diagram
AD1882JCPZ Original Integrated Circuit High Definition Audio SoundMAX Codec
