Introduction
The TVP9900 is a cost-effective digital TV (DTV) front-end IC targeted for low-cost high-volume DTV receivers. The TVP9900 is a system-on-chip (SoC) device that integrates the main functions of a DTV front-end system, including programmable gain amplifier (PGA), A/D converter, VSB demodulator, ATSC forward error correction (FEC), QAM demodulator, and ITU-T Annex B FEC. It provides rich peripheral support including AGC control, tuner control, CEA-909 antenna control, and host I 2C interface. The TVP9900 supports processing of ATSC VSB or ITU-T Annex B QAM IF inputs.
Features
• ATSC 8-VSB Demodulation and FEC
• ITU-J.83B Compliant 64/256 QAM Demodulation and FEC
• Direct 44-MHz IF Sampling Eliminates Need for
• BER Monitor External Downconverter
• Integrated IF PGA
• Integrated High-Speed 10-bit A/D Converter
• Integrated Digital Filter Relaxes External Tuner
• Direct Tuner Control Interface Filters
• Sigma-Delta DAC for AGC Control
• Adjacent Channel Filter
• NTSC Co-Channel Rejection Filter
• All Digital Timing Recovery
Ordering Information(1)
TA | PACKAGED DEVICES | PACKAGE OPTION |
80-Pin TQFP-PowerPAD | ||
0°C to 70°C | TVP9900PFP | Tray |
TVP9900PFPR | Tape and Reel |
Block Diagram
