MC34071P Integrated Circuit Chip HIGH BANDWIDTH SINGLE SUPPLY OPERATIONAL AMPLIFIERS

Good quality Programmable IC Chips for sales
Good quality Programmable IC Chips for sales
We have cooperate with Anterwell near 7 years. always very good quality good service. Original and very fast delivery. A very good partner.

—— Clemente From Brzail

I'm doing business with Anterwell from 2006, from small to big orders. Reliable!

—— Ingalill From Sweden

Sharon is a very good girl, we are very happy to cooperate with her. Competitive price and professional. Never have quality problem with them.

—— Alfredo From USA

We always buy XILINX parts from Anterwell. High quality with good price. Hope can have more business with you.

—— Mr Babak From Iran

I'm Online Chat Now

MC34071P Integrated Circuit Chip HIGH BANDWIDTH SINGLE SUPPLY OPERATIONAL AMPLIFIERS

China MC34071P Integrated Circuit Chip HIGH BANDWIDTH SINGLE SUPPLY OPERATIONAL AMPLIFIERS supplier

Large Image :  MC34071P Integrated Circuit Chip HIGH BANDWIDTH SINGLE SUPPLY OPERATIONAL AMPLIFIERS

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: MC34071P

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 5600pcs
Contact Now
Detailed Product Description
Supply Voltage: +44 V Output Short Circuit Duration: Indefinite
Operating Junction Temperature: +150 °C Storage Temperature Range: –60 To +150 °C
Wide Bandwidth: 4.5 MHz High Slew Rate: 13 V/µs
High Light:

small scale integrated circuits

,

integrated components



HIGH BANDWIDTH SINGLE SUPPLY OPERATIONAL AMPLIFIERS



Quality bipolar fabrication with innovative design concepts are employed for the MC33071/72/74, MC34071/72/74 series of monolithic operational amplifiers. This series of operational amplifiers offer 4.5 MHz of gain bandwidth product, 13 V/µs slew rate and fast setting time without the use of JFET device technology. Although this series can be operated from split supplies, it is particularly suited for single supply operation, since the common mode input voltage range includes ground potential (VEE). With A Darlington input stage, this series exhibits high input resistance, low input offset voltage and high gain. The all NPN output stage, characterized by no deadband crossover distortion and large output voltage swing, provides high capacitance drive capability, excellent phase and gain margins, low open loop high frequency output impedance and symmetrical source/sink AC frequency response.

The MC33071/72/74, MC34071/72/73 series of devices are available in standard or prime performance (A Suffix) grades and are specified over the commercial, industrial/vehicular or military temperature ranges. The complete series of single, dual and quad operational amplifiers are available in plastic DIP and SOIC surface mount packages.



• Wide Bandwidth: 4.5 MHz

• High Slew Rate: 13 V/µs

• Fast Settling Time: 1.1 µs to 0.1%

• Wide Single Supply Operation: 3.0 V to 44 V

• Wide Input Common Mode Voltage Range: Includes Ground (VEE)

• Low Input Offset Voltage: 3.0 mV Maximum (A Suffix)

• Large Output Voltage Swing: –14.7 V to +14 V (with ±15 V Supplies)

• Large Capacitance Drive Capability: 0 pF to 10,000 pF

• Low Total Harmonic Distortion: 0.02%

• Excellent Phase Margin: 60°

• Excellent Gain Margin: 12 dB

• Output Short Circuit Protection

• ESD Diodes/Clamps Provide Input Protection for Dual and Quad



MAXIMUM RATINGS

Rating Symbol Value Unit
Supply Voltage (from VEE to VCC) VS +44 V
Input Differential Voltage Range VIDR Note 1 V
Input Voltage Range VIR Note 1 V
Output Short Circuit Duration (Note 2) tSC Indefinite sec
Operating Junction Temperature TJ +150 °C
Storage Temperature Range Tstg –60 to +150 °C

NOTES: 1. Either or both input voltages should not exceed the magnitude of VCC or VEE.

2. Power dissipation must be considered to ensure maximum junction temperature (TJ) is not exceeded (see Figure 1).



Representative Schematic Diagram (Each Amplifier)
