Product Details:
Payment & Shipping Terms:
|
| VIN Range: | –0.3 To +7.0 V | VEN Range: | –0.3 To VIN +0.3 V |
|---|---|---|---|
| VOUT Range: | –0.3 To VIN +0.3 V | VFB Range: | –0.3 To VFB (TYP) +0.3 V |
| Peak Output Current I: | Internally Limited | ||
| High Light: | electronic integrated circuit,digital integrated circuits |
||
500mA, Low Quiescent Current, Ultra-Low Noise, High PSRR
Low Dropout Linear Regulator
DESCRIPTION
The TPS735xx family of low-dropout (LDO), low-power linear regulators offers excellent ac performance with very low ground current. High power-supply rejection ratio (PSRR), low noise, fast start-up, and excellent line and load transient response are provided while consuming a very low 46μA (typical) ground current. The TPS735xx is stable with ceramic capacitors and uses an advanced BiCMOS fabrication process to yield a typical dropout voltage of 250mV at 500mA output. The TPS735xx uses a precision voltage reference and feedback loop to achieve overall accuracy of 2% (VOUT > 2.2V) over all load, line, process, and temperature variations. It is fully specified from TJ = –40°C to +125°C and is offered in low-profile, 2mm x 2mm SON and 3mm × 3mm SON packages that are ideal for wireless handsets, printers, and WLAN cards.
ABSOLUTE MAXIMUM RATINGS
Over operating temperature range (unless otherwise noted).(1)
| PARAMETER | TPS735xx | UNIT |
| VIN range | –0.3 to +7.0 | V |
| VEN range | –0.3 to VIN +0.3 | V |
| VOUT range | –0.3 to VIN +0.3 | V |
| VFB range | –0.3 to VFB (TYP) +0.3 | V |
