Miniature, 1W Isolated
UNREGULATED DC/DC CONVERTERS
FEATURES
*Up To 85% Efficiency
*Thermal Protection
*Device-to-Device Synchronization
*Short-Circuit Protection
*EN55022 Class B EMC Performance
*UL1950 Recognized Component
*JEDEC DIP-14 and SOP-14 Packages
APPLICATIONS
*Point-of-Use Power Conversion
*Ground Loop Elimination
*Data Acquisition
*Industrial Control and Instrumentation
*Test Equipment
DESCRIPTION
The DCP01B series is a family of 1W, unregulated, isolated DC/DC converters. Requiring a minimum of external components and including on-chip device protection, the DCP01B series provides extra features such as output disable and synchronization of switching frequencies. The use of a highly-integrated package design results in highly reliable products with a power density of 40W/in3 (2.4W/cm3). This combination of features and small sizes makes the DCP01B suitable for a wide range of applications.
DCP01B SERIES | UNIT | ||
Input voltage | 5V models | 7 | V |
15V models | 18 | V | |
24V models | 29 | V | |
Storage temperature | −40 to +125 | °C | |
Lead temperature (soldering, 10s) | +270 | °C |
Notice:
Stresses above these ratings may cause permanent damage. Exposure to absolute maximum conditions for extended periods may degrade device reliability. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those specified is not implied.
