10V CAP 10㎌ Multilayer Ceramic Chip Capacitors CL21B106KOQNNNE

China 10V CAP 10㎌ Multilayer Ceramic Chip Capacitors CL21B106KOQNNNE supplier
10V CAP 10㎌ Multilayer Ceramic Chip Capacitors CL21B106KOQNNNE supplier 10V CAP 10㎌ Multilayer Ceramic Chip Capacitors CL21B106KOQNNNE supplier

Large Image :  10V CAP 10㎌ Multilayer Ceramic Chip Capacitors CL21B106KOQNNNE

Product Details:

Place of Origin: China
Brand Name: Anterwell
Certification: Original Factory Pack
Model Number: CL21B106KOQNNNE

Payment & Shipping Terms:

Minimum Order Quantity: 4000pcs
Price: Negotiation
Packaging Details: SMD0805 4000pcs/reel
Delivery Time: 1 Day
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 200000PCS
Contact Now
Detailed Product Description
Package: SMD0805 Factory Pack: 4000pcs/Reel
Product: Multi-layer Ceramic Capacitor Description :: CAP,10㎌
Voltage: 10V Maim Line: Ic,module,transistor,diodes,capacitor,resistor Etc
High Light:

ferrite bead model

,

smd ceramic capacitor

10V CAP 10㎌ Multilayer Ceramic Chip Capacitors CL21B106KOQNNNE





SPECIFICATION (Reference sheet)

· Supplier : Samsung electro-mechanics

· Samsung P/N : CL21B106KOQNNNE

· Product : Multi-layer Ceramic Capacitor

· Description : CAP, 10㎌, 10V, ±10%, X5R, 0805



CL  21   B      *      *        *     *   N    N    N    E

①   ②   ③    ④     ⑤    ⑥   ⑦   ⑧   ⑨  ⑩   ⑪



① Series Samsung Multi-layer Ceramic Capacitor
② Size 0805 (inch code) L: 2.0 ± 0.1 mm W: ± 0.1 mm
③ Dielectric X5R
④ Capacitance  4.7 ㎌
⑤ Capacitance tolerance ±10 %
⑥ Rated Voltage 10 V
⑦ Thickness 1.25 ± 0.1 mm

⑧ Inner electrode Ni

    Termination  Cu

    Plating  Sn 100%  (Pb Free)

⑨ Product Normal
⑩ Special Reserved for future use
⑪ Packaging Cardboard Type, 7" reel




10V CAP 10㎌ Multilayer Ceramic Chip Capacitors CL21B106KOQNNNE

  Performance Test condition
Capacitance Within specified tolerance
1㎑±10% 1.0±0.2Vrms
Tan δ (DF) 0.1 max
Insulation Resistance

10,000Mohm or 100Mohm⋅㎌

Whichever is Smaller

Rated Voltage 60~120 sec.
Appearance No abnormal exterior appearance Microscope (×10)
Withstanding  Voltage  No dielectric breakdown or mechanical breakdown   250% of the rated voltage
Temperature  Characterisitcs X5R (From -55℃ to 85℃, Capacitance change shoud be within ±15%)



D. Recommended Soldering method :



Reflow ( Reflow Peak Temperature : 260+0/-5℃, 10sec. Max )





Product specifications included in the specifications are effective as of March 1, 2013.

Please be advised that they are standard product specifications for reference only.

We may change, modify or discontinue the product specifications without notice at any time.

So, you need to approve the product specifications before placing an order.

Should you have any question regarding the product specifications, please contact our sales personnel or application engineers.



★ Capacitor/Resistor/Inductance SMD SIZE & PACKAGE ★

International Code Size Code Reel Quantity
(pcs)
Length
(mm)
Width
(mm)
Thickness
(mm)
01005 0402 20000 0.25 0.125 0.13
0201 0603 10000 0.6 0.3 0.3
0402 1005 10000 1.00±0.05 0.05±0.05 0.50±0.05
0603 1608 4000-5000 1.60±0.10 0.80±0.10 0.80±0.10
0805 2012 4000-5000 2.00±0.20 1.25±0.20 0.70±0.20
1206 3216 2000 3.20±0.30 1.60±0.20 0.70±0.20
1210 3225 2000 3.20±0.30 2.50±0.30 1.25±0.30
1808 4520 1000 4.50±0.40 2.00±0.20 2.00±0.30
1812 4532 1000 4.50±0.40 3.20±0.30 2.50±0.30
1825 4564 1000 4.50±0.40 6.40±0.40 0.61±0.36
2225 5764 1000 5.70±0.50 6.40±0.50 2.50±0.30
2512 6332 500 6.30±0.50 3.20±0.50 2.50±0.30
3035 7690 400 7.60±0.50 9.00±0.05 3.00±0.30
case A 3216 2000 3.20±0.20 1.60±0.20 1.60±0.20
case B 3528 2000 3.50±0.20 2.80±0.20 1.90±0.20
case C 6032 500 6.00±0.20 3.20±0.20 2.60±0.20
case D 7343 500 30±0.20 4.30±0.20 2.80±0.20
case E 7343H 400 7.30±0.20 4.10±0.20 4.00±0.20
