Digital Integrated Circuit Chip DAC0832LCN 8 Bit D To A Converter IC

Good quality Programmable IC Chips for sales
Good quality Programmable IC Chips for sales
We have cooperate with Anterwell near 7 years. always very good quality good service. Original and very fast delivery. A very good partner.

—— Clemente From Brzail

I'm doing business with Anterwell from 2006, from small to big orders. Reliable!

—— Ingalill From Sweden

Sharon is a very good girl, we are very happy to cooperate with her. Competitive price and professional. Never have quality problem with them.

—— Alfredo From USA

We always buy XILINX parts from Anterwell. High quality with good price. Hope can have more business with you.

—— Mr Babak From Iran

I'm Online Chat Now

Digital Integrated Circuit Chip DAC0832LCN 8 Bit D To A Converter IC

China Digital Integrated Circuit Chip DAC0832LCN 8 Bit D To A Converter IC supplier

Large Image :  Digital Integrated Circuit Chip DAC0832LCN 8 Bit D To A Converter IC

Product Details:

Place of Origin: Thailand
Brand Name: NSC
Certification: Original Factory Pack
Model Number: DAC0832LCN

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: please contact me for details
Delivery Time: 1 Day
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 290PCS
Contact Now
Detailed Product Description
Feature: Double-buffered, Single-buffered Or Flow-through Digital Data Inputs Feature2: Easy Interchange And Pin-compatible With 12-bit DAC1230 Series
Feature3: Direct Interface To All Popular Microprocessors Feature4: Linearity Specified With Zero And Full Scale Adjust Only — NOT BEST STRAIGHT LINE FIT.
Feature5: Works With ±10V Reference-full 4-quadrant Multiplication Package: DIP-20

Digital Integrated Circuit Chip DAC0832LCN 8 Bit D To A Converter IC







DAC0830/DAC0832

8-Bit µP Compatible, Double-Buffered D to A Converters

General Description



The DAC0830 is an advanced CMOS/Si-Cr 8-bit multiplying DAC designed to interface directly with the 8080, 8048, 8085, Z80®, and other popular microprocessors. A deposited silicon-chromium R-2R resistor ladder network divides the reference current and provides the circuit with excellent temperature tracking characteristics (0.05% of Full Scale Range maximum linearity error over temperature).



The circuit uses CMOS current switches and control logic to achieve low power consumption and low output leakage current errors. Special circuitry provides TTL logic input voltage level compatibility.



Double buffering allows these DACs to output a voltage corresponding to one digital word while holding the next digital word. This permits the simultaneous updating of any number of DACs. The DAC0830 series are the 8-bit members of a family of microprocessor-compatible DACs (MICRO-DAC™).





Features

n Double-buffered, single-buffered or flow-through digital data inputs

n Easy interchange and pin-compatible with 12-bit DAC1230 series

n Direct interface to all popular microprocessors

n Linearity specified with zero and full scale adjust only — NOT BEST STRAIGHT LINE FIT.

n Works with ±10V reference-full 4-quadrant multiplication

n Can be used in the voltage switching mode

n Logic inputs which meet TTL voltage level specs (1.4V logic threshold)

n Operates “STAND ALONE” (without µP) if desired

n Available in 20-pin small-outline or molded chip carrier package



Key Specifications

n Current settling time: 1 µs

n Resolution: 8 bits

n Linearity: 8, 9, or 10 bits (guaranteed over temp.)

n Gain Tempco: 0.0002% FS/˚C

n Low power dissipation: 20 mW

n Single power supply: 5 to 15 VDC





Typical Application

Digital Integrated Circuit Chip DAC0832LCN 8 Bit D To A Converter IC

Connection Diagrams (Top Views)



Digital Integrated Circuit Chip DAC0832LCN 8 Bit D To A Converter IC
