EE2-5NU-L Compact and lightweight , High breakdown voltage Surface mounting type

: Large Image : EE2-5NU-L Compact and lightweight , High breakdown voltage Surface mounting type

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	EE2-5NU-L

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8200pcs

Contact Now

Detailed Product Description

Contact Current Rating:	2A	Coil Voltage:	5V
Max Switching Current:	2A	Power Dissipation:	140 MW
Packing:	Reel	Factory Packing Quantity:	500
Highlight:	chip in electronics , integrated components

EE2-5NU-L Compact and lightweight, High breakdown voltage, Surface mounting type

DESCRIPTION

The EE2 series surface-mounting type sustaining high-performance of NEC EC2 series.

FEATURES

Compact and light weight

2 form c contact arrangement

Low power consumption

Reduced mounting space : 15 mm × 9.5 mm

High-breakdown voltage of coil to contacts : 1500 Vac, 2500 V (rise time : 2 µs, fall time : 10 µs)

Low power consumption : 100 to 140 mW

Capable of High-power switching : 700 Vac, 4.2 A, 4 times in case of accident

UL recognized (E73266), CAS certified (LR46266)

APPLICATIONS

Electronic switching systems, PBX, terminal equipment, telephone system.

EE2-5NU-L Compact and lightweight , High breakdown voltage Surface mounting type

PART NUMBER SYSTEM

EE2-5NU-L Compact and lightweight , High breakdown voltage Surface mounting type

OUTLINE DRAWINGS AND DIMENSIONS

EE2-5NU-L Compact and lightweight , High breakdown voltage Surface mounting type

PAD LAYOUTS (bottom view)

EE2-5NU-L Compact and lightweight , High breakdown voltage Surface mounting type
