GP02-20-E3-73 Electronic IC Chips HIGH VOLTAGE GLASS PASSIVATED JUNCTION RECTIFIER

: Large Image : GP02-20-E3-73 Electronic IC Chips HIGH VOLTAGE GLASS PASSIVATED JUNCTION RECTIFIER

Product Details:

Place of Origin:	original factory
Brand Name:	VISHAY
Certification:	new & original
Model Number:	GP02-20-E3-73

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	9500pcs

Contact Now

Detailed Product Description

I(AV):	0.25 Amp	IFSM:	15.0 Amps
VF:	3.0Volts	CJ:	3.0 PF
RΘJA:	130.0°C/W	TJ, TSTG:	-65 To +175°C
Highlight:	electronic integrated circuit , linear integrated circuits

GP02-20-E3-73 HIGH VOLTAGE GLASS PASSIVATED JUNCTION RECTIFIER

FEATURES
♦ Plastic package has Underwriters Laboratory Flammability Classification 94V-0
♦ High temperature metallurgically bonded construction
♦ Glass passivated cavity-free junctions
♦ Capable of meeting environmental standards of MIL-S-19500

♦ High temperature soldering guaranteed: 350°C/10 seconds, 0.375" (9.5mm) lead length, 5 lbs. (2.3kg) tension

MECHANICAL DATA

Case: JEDEC DO-204AL molded plastic over glass body
Terminals: Plated axial leads, solderable per MIL-STD-750, Method 2026
Polarity: Color band denotes cathode end
Mounting Position: Any
Weight: 0.012 ounce, 0.3 gram

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

	SYMBOLS	GP02-20	UNITS
Maximum repetitive peak reverse voltage	VRRM	2000	Volts
Maximum RMS Voltage	VRMS	1400	Volts
Maximum DC blocking voltage	VDC	2000	Volts
Maximum average forward rectified current 0.375" (9.5mm) lead length at TA=55°C	I(AV)	0.25	Amp
Peak forward surge current 8.3ms single half sine-wave superimposed on rated load at:(JEDEC Method) TA=55°C	IFSM	15.0	Amps
Maximum instantaneous forward voltage at 1.0A	VF	3.0	Volts
Maximum DC reverse current TA= 25°C at rated DC blocking voltage TA=100°C	IR	5.0 50.0	µA
Typical reverse recovery time (NOTE 1)	trr	2.0	µs
Typical junction capacitance (NOTE 2)	CJ	3.0	pF
Typical thermal resistance (NOTE 3)	RΘJA	130.0	°C/W
Operating junction and storage temperature range	TJ, TSTG	-65 to +175	°C

NOTES: (1) Reverse recovery test conditions: IF=0.5A, IR=1.0A, Irr=0.25A
(2) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
(3) Thermal resistance from junction to ambient at 0.375" (9.5mm) lead lengths, P.C.B. mounted

GP02-20-E3-73 Electronic IC Chips HIGH VOLTAGE GLASS PASSIVATED JUNCTION RECTIFIER
