PC929 Electronic IC Chips Shortcircuit Protector Circuit Built-in Photocoupler

: Large Image : PC929 Electronic IC Chips Shortcircuit Protector Circuit Built-in Photocoupler

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	PC929

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8000pcs

Contact Now

Detailed Product Description

Forward Current:	20 MA	Reverse Voltage:	6 V
Supply Voltage:	35 V	Total Power Dissipation:	550 MW
Isolation Voltage:	4 000 Vrms	Operating Temperature:	- 25 To + 80 ˚C
High Light:	electronic integrated circuit , linear integrated circuits

PC929 Shortcircuit Protector Circuit Built-in Photocoupler Suitable for Inverter-Driving MOS-FET/IGBT

Features

1. Built-in IGBT shortcircuit protector circuit

2. Built-in direct drive circuit for IGBT drive (Peak output current ... I_O1P, I_O2P : MAX. 0.4A)

3. High speed response (t_PLH, t_PHL : MAX. 0.5 µ s)

4. High isolation voltage (V_iso : 4000Vrms)

5. Half lead pin pitch (p=1.27 mm) package type

6. Recognized by UL, file NO. E64380

Application

1. IGBT control for inverter drive

Absolute Maximum Ratings (Ta=Topr unless otherwise specified)

Parameter		Symbol	Rating	Unit
Input	*1 Forward current	I_F	20	mA
Input	Reverse voltage	V_R	6 (Ta= 25˚C)	V
Output	Supply voltage	V_CC	35	V
	O₁ output current	I_O1	0.1	A
	*4 O₁ peak output current	I_O1P	0.4	A
	O₂ output current	I_O2	0.1	A
	*4 O₂ peak output current	I_O2P	0.4	A
	O₁ output voltage	V_O1	35	V
	*2 Power dissipation	P_O	500	mW
	Overcurrent detecting voltage	V_C	V_CC	V
	Overcurrent detecting current	I_C	30	mA
	Error signal output voltage	V_FS	V_CC	V
	Error signal output current	I_FS	20	mA
*3 Total power dissipation		Ptot	550	mW
*5 Isolation voltage		Viso	4000	Vrms
Operating temperature		Topr	- 25 to + 80	˚C
Storage temperature		Tstg	- 55 to + 125	˚C
Soldering temperature		Tsol	260 (for 10 sec)	˚C

*1, 2, 3 Decrease in the ambient temperature range of the Absolute Max. Rating : Shown in Figs 1 and 2.

*4 Pulse width <=0.15 µs, Duty ratio=0.01

*5 40 to 60% RH, AC for 1 minute, Ta=25˚C

Outline Dimensions (Unit : mm)
