LTC4355CMS Electronic IC Chips Positive High Voltage Ideal Diode-OR

Good quality Programmable IC Chips for sales
Good quality Programmable IC Chips for sales
We have cooperate with Anterwell near 7 years. always very good quality good service. Original and very fast delivery. A very good partner.

—— Clemente From Brzail

I'm doing business with Anterwell from 2006, from small to big orders. Reliable!

—— Ingalill From Sweden

Sharon is a very good girl, we are very happy to cooperate with her. Competitive price and professional. Never have quality problem with them.

—— Alfredo From USA

We always buy XILINX parts from Anterwell. High quality with good price. Hope can have more business with you.

—— Mr Babak From Iran

I'm Online Chat Now

LTC4355CMS Electronic IC Chips Positive High Voltage Ideal Diode-OR

China LTC4355CMS Electronic IC Chips Positive High Voltage Ideal Diode-OR supplier

Large Image :  LTC4355CMS Electronic IC Chips Positive High Voltage Ideal Diode-OR

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: LTC4355CMS

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 9000pcs
Contact Now
Detailed Product Description
Operating Supply: 9 To 80 V Supply Current: 2 MA
INx Pin Input Current: 0.6 MA External N-Channel Gate Pull-Up Current: -20 μA
External N-Channel Gate Pull-Down In Fault Condition: 2 A Gate Turn-Off Time: 0.3 μs



LTC4355

Positive High Voltage Ideal Diode-OR with Input Supply and Fuse Monitors



FEATURES

• Replaces Power Schottky Diodes

• Controls N-Channel MOSFETs

• 0.3μs Turn-Off Time Limits Peak Fault Current

• Wide Operating Voltage Range: 9V to 80V

• Smooth Switchover without Oscillation

• No Reverse DC Current

• Monitors VIN, Fuse, and MOSFET Diode

• Available in 14-Lead (4mm × 3mm) DFN, 16-Lead MS and SO Packages



APPLICATIONS

• High Availability Systems

• AdvancedTCA® (ATCA) Systems

• +48V and –48V Distributed Power Systems

• Telecom Infrastructure



DESCRIPTION

The LTC®4355 is a positive voltage ideal diode-OR controller that drives two external N-channel MOSFETs. Forming the diode-OR with N-channel MOSFETs instead of Schottky diodes reduces power consumption, heat dissipation and PC board area.



With the LTC4355, power sources can easily be ORed together to increase total system reliability. The LTC4355 can diode-OR two positive supplies or the return paths of two negative supplies, such as in a –48V system.



In the forward direction the LTC4355 controls the voltage drop across the MOSFET to ensure smooth current transfer from one path to the other without oscillation. If a power source fails or is shorted, fast turnoff minimizes reverse current transients.



Power fault detection indicates if the input supplies are not in regulation, the inline fuses are blown, or the voltages across the MOSFETs are greater than the fault threshold.



TYPICAL APPLICATION

LTC4355CMS Electronic IC Chips Positive High Voltage Ideal Diode-OR



LTC4355CMS Electronic IC Chips Positive High Voltage Ideal Diode-OR



ABSOLUTE MAXIMUM RATINGS (Notes 1, 2)

Supply Voltages

    IN1, IN2 .................................................. –1V to 100V

    OUT ..................................................... –0.3V to 100V

Input Voltages

    MON1, MON2, SET .................................. –0.3V to 7V

Output Voltages

    GATE1 (Note 3) ................... VIN1 – 0.2V to VIN1 + 13V

    GATE2 (Note 3) ................... VIN2 – 0.2V to VIN2 + 13V

    PWRFLT1, PWRFLT2, VDSFLT,

    FUSEFLT1, FUSEFLT2 ............................... –0.3V to 8V

Operating Temperature Range

    LTC4355C ................................................ 0°C to 70°C

    LTC4355I..............................................–40°C to 85°C

Storage Temperature Range ...................–65°C to 150°C

Lead Temperature (Soldering, 10 sec)

    MS, SO Packages ............................................. 300°C
