DS75176BMX Electronic IC Chips Multipoint RS-485/RS-422 Transceivers

Good quality Programmable IC Chips for sales
Good quality Programmable IC Chips for sales
We have cooperate with Anterwell near 7 years. always very good quality good service. Original and very fast delivery. A very good partner.

—— Clemente From Brzail

I'm doing business with Anterwell from 2006, from small to big orders. Reliable!

—— Ingalill From Sweden

Sharon is a very good girl, we are very happy to cooperate with her. Competitive price and professional. Never have quality problem with them.

—— Alfredo From USA

We always buy XILINX parts from Anterwell. High quality with good price. Hope can have more business with you.

—— Mr Babak From Iran

I'm Online Chat Now

DS75176BMX Electronic IC Chips Multipoint RS-485/RS-422 Transceivers

China DS75176BMX Electronic IC Chips Multipoint RS-485/RS-422 Transceivers supplier

Large Image :  DS75176BMX Electronic IC Chips Multipoint RS-485/RS-422 Transceivers

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: DS75176BMX

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 9000pcs
Contact Now
Detailed Product Description
Supply Voltage: 7 V Control Input Voltages: 7 V
Driver Input Voltage: 7 V Driver Output Voltages: +15V/ −10V
Storage Temperature: −65°C To +150°C Lead Temperature (Soldering, 4 Seconds): 260°C
High Light:

electronic integrated circuit

,

linear integrated circuits



DS75176B/DS75176BT Multipoint RS-485/RS-422 Transceivers



FEATURES

• Meets EIA Standard RS485 for Multipoint Bus Transmission and is Compatible with RS-422.

• Small Outline (SOIC) Package Option Available for Minimum Board Space.

• 22 ns Driver Propagation Delays.

• Single +5V Supply.

• −7V to +12V Bus Common Mode Range Permits ±7V Ground Difference Between Devices on the Bus.

• Thermal Shutdown Protection.



• High Impedance to Bus with Driver in TRI-STATE or with Power Off, Over the Entire Common Mode Range Allows the Unused Devices on the Bus to be Powered Down.

• Pin Out Compatible with DS3695/A and SN75176A/B.

• Combined Impedance of a Driver Output and Receiver Input is Less Than One RS485 Unit Load, Allowing up to 32 Transceivers on the Bus.

• 70 mV Typical Receiver Hysteresis.



DESCRIPTION

The DS75176B is a high speed differential TRI-STATE®bus/line transceiver designed to meet the requirements of EIA standard RS485 with extended common mode range (+12V to −7V), for multipoint data transmission. In addition, it is compatible with RS-422.



The driver and receiver outputs feature TRI-STATE capability, for the driver outputs over the entire common mode range of +12V to −7V. Bus contention or fault situations that cause excessive power dissipation within the device are handled by a thermal shutdown circuit, which forces the driver outputs into the high impedance state.



DC specifications are guaranteed over the 0 to 70°C temperature and 4.75V to 5.25V supply voltage range.



Connection and Logic Diagram

DS75176BMX Electronic IC Chips Multipoint RS-485/RS-422 Transceivers



Absolute Maximum Ratings (1)(2)

Supply Voltage, VCC 7V
Control Input Voltages 7V
Driver Input Voltage 7V
Driver Output Voltages +15V/ −10V
Receiver Input Voltages (DS75176B) +15V/ −10V
Receiver Output Voltage 5.5V
Continuous Power Dissipation @ 25°C for SOIC Package 675 mW (3)
for PDIP Package 900 mW (4)
Storage Temperature Range −65°C to +150°C
Lead Temperature (Soldering, 4 seconds) 260°C
ESD Rating (HBM) 500V

(1) “Absolute Maximum Ratings” are those beyond which the safety of the device cannot be verified. They are not meant to imply that the device should be operated at these limits. The tables of “Electrical Characteristics” provide conditions for actual device operation.

(2) If Military/Aerospace specified devices are required, please contact the TI Sales Office/Distributors for availability and specifications.

(3) Derate linearly @ 6.11 mW/°C to 400 mW at 70°C.

(4) Derate linearly at 5.56 mW/°C to 650 mW at 70°C.









Stock Offer (Hot Sell)
