KSZ8041RNL-TR Electronic IC Chip 10Base-T/100Base-TX Physical Layer Transceiver

KSZ8041NL/RNL

10Base-T/100Base-TX Physical Layer Transceiver

General Description

The KSZ8041NL is a single supply 10Base-T/100Base-TX Physical Layer Transceiver, which provides MII/RMII interfaces to transmit and receive data. A unique mixed signal design extends signaling distance while reducing power consumption.

HP Auto MDI/MDI-X provides the most robust solution for eliminating the need to differentiate between crossover and straight-through cables.

The KSZ8041NL represents a new level of features and performance and is an ideal choice of physical layer transceiver for 10Base-T/100Base-TX applications.

The KSZ8041RNL is an enhanced RMII version of the KSZ8041NL that does not require a 50MHz system clock. It uses a 25MHz crystal for its input reference clock and outputs a 50MHz RMII reference clock to the MAC.

The KSZ8041NL and KSZ8041RNL are available in 32- pin, lead-free MLF® (QFN per JDEC) packages (See Ordering Information).

Features

• Single-chip 10Base-T/100Base-TX physical layer solution

• Fully compliant to IEEE 802.3u Standard

• Low power CMOS design, power consumption of <180mW

• HP auto MDI/MDI-X for reliable detection and correction for straight-through and crossover cables with disable and enable option

• Robust operation over standard cables

• Power down and power saving modes

• MII interface support (KSZ8041NL only)

• RMII interface support with external 50MHz system clock (KSZ8041NL only)

• RMII interface support with 25MHz crystal/clock input and 50MHz reference clock output to MAC (KSZ8041RNL only)

• MIIM (MDC/MDIO) management bus to 6.25MHz for rapid PHY register configuration

• Interrupt pin option

• Programmable LED outputs for link, activity and speed

• ESD rating (6kV)

• Single power supply (3.3V)

• Built-in 1.8V regulator for core

• Available in 32-pin (5mm x 5mm) MLF® package

Applications

• Printer

• LOM

• Game Console

• IPTV

• IP Phone

• IP Set-top Box

Absolute Maximum Ratings⁽¹⁾

Supply Voltage

    (V_{DDPLL_1.8}).............................................. -0.5V to +2.4V

    (V_{DDIO_3.3}, V_{DDA_3.3}) ............................... -0.5V to +4.0V

Input Voltage (all inputs) ............................... -0.5V to +4.0V

Output Voltage (all outputs) .......................... -0.5V to +4.0V

Lead Temperature (soldering, 10sec.)....................... 260°C

Storage Temperature (Ts) ..........................-55°C to +150°C

ESD Rating⁽³⁾..................................................................6kV

Operating Ratings⁽²⁾

Supply Voltage

    (V_{DDIO_3.3}, V_{DDA_3.3}) .......................... +3.135V to +3.465V

Ambient Temperature

    (T_A , Commercial)......................................0°C to +70°C

    (T_A , Industrial) .......................................-40°C to +85°C

    (T_A , AM Automotive Qualified) ............. -40°C to +85°C

Maximum Junction Temperature (T_J Max) ................. 125°C

Maximum Case Temperature (T_C Max)...................... 150°C

Thermal Resistance (θ_JA) .........................................34°C/W

Thermal Resistance (θ_JC)...........................................6°C/W

Notes:

1. Exceeding the absolute maximum rating may damage the device. Stresses greater than the absolute maximum rating may cause permanent damage to the device. Operation of the device at these or any other conditions above those specified in the operating sections of this specification is not implied. Maximum conditions for extended periods may affect reliability.

2. The device is not guaranteed to function outside its operating rating.

3. Devices are ESD sensitive. Handling precautions recommended. Human body model, 1.5k in series with 100pF.
