NDT456P Power Mosfet Transistor P-Channel Field Effect Transistor

: Large Image : NDT456P Power Mosfet Transistor P-Channel Field Effect Transistor

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	NDT456P

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	6900pcs

Contact Now

Detailed Product Description

Drain-Source Voltage:	-30 V	Gate-Source Voltage:	±20 V
Operating And Storage Temperature:	-65 To 150 °C	Package:	SOT-223
High Light:	power mosfet ic , multi emitter transistor

Drain-Source Voltage:

-30 V

Gate-Source Voltage:

±20 V

Operating And Storage Temperature:

-65 To 150 °C

Package:

SOT-223

High Light:

power mosfet ic

multi emitter transistor

NDT456P P-Channel Enhancement Mode Field Effect Transistor

General Description

Power SOT P-Channel enhancement mode power field effect transistors are produced using Fairchild's proprietary, high cell density, DMOS technology. This very high density process is especially tailored to minimize on-state resistance and provide superior switching performance. These devices are particularly suited for low voltage applications such as notebook computer power management, battery powered circuits, and DC motor control.

Features

-7.5 A, -30 V. R_DS(ON)= 0.030 W @ V_GS = -10 V
R_DS(ON) = 0.045 W @ VGS = -4.5 V.
High density cell design for extremely low R_DS(ON).
High power and current handling capability in a widely used surface mount package.

Absolute Maximum Ratings T_A = 25°C unless otherwise noted

Symbol	Parameter	NDT456P	Units
V_DSS	Drain-Source Voltage	-30	V
V_GSS	Gate-Source Voltage	±20	V
I_D	Drain Current - Continuous (Note 1a) - Pulsed	±7.5	A
I_D	Drain Current - Continuous (Note 1a) - Pulsed	±20	A
P_D	Maximum Power Dissipation (Note 1a) (Note 1b) (Note 1c)	3	W
		1.3	W
		1.1	W
T_J,T_STG	Operating and Storage Temperature Range	-65 to 150	°C
