MC1496, MC1496B
Balanced Modulators/ Demodulators
These devices were designed for use where the output voltage is a product of an input voltage (signal) and a switching function (carrier). Typical applications include suppressed carrier and amplitude modulation, synchronous detection, FM detection, phase detection, and chopper applications. See ON Semiconductor Application Note AN531 for additional design information.
Features
• Excellent Carrier Suppression −65 dB typ @ 0.5 MHz
−50 dB typ @ 10 MHz
• Adjustable Gain and Signal Handling
• Balanced Inputs and Outputs
• High Common Mode Rejection −85 dB Typical
• This Device Contains 8 Active Transistors
• Pb−Free Package is Available*
MAXIMUM RATINGS (TA = 25°C, unless otherwise noted.)
Rating | Symbol | Value | Unit |
Applied Voltage (V6−V8, V10−V1, V12−V8, V12−V10, V8−V4, V8−V1, V10−V4, V6−V10, V2−V5, V3−V5) |
△V | 30 | Vdc |
Differential Input Signal |
V8 − V10 V4 − V1 |
+5.0 ±(5+I5Re) |
Vdc |
Maximum Bias Current | I5 | 10 | mA |
Thermal Resistance, Junction−to−Air Plastic Dual In−Line Package |
RθJA | 100 | °C/W |
Operating Ambient Temperature Range MC1496 MC1496B |
TA |
0 to +70 −40 to +125 |
°C |
Storage Temperature Range | Tstg | −65 to +150 | °C |
Electrostatic Discharge Sensitivity (ESD) Human Body Model (HBM) Machine Model (MM) |
ESD |
2000 400 |
V |
