Product Details:
Payment & Shipping Terms:
|
Output Voltage: | 5.0 Vdc | Output Voltage Variation: | 4.75 − 5.25 Vdc |
---|---|---|---|
Line Regulation: | 3.0 MV | Input Bias Current: | 3.2 MA |
Output Noise Voltage: | 40 μV | Dropout Voltage: | 2.0 Vdc |
High Light: | electronic integrated circuit,linear integrated circuits |
MC78M00, MC78M00A Series
500 mA Positive Voltage Regulators
The MC78M00/MC78M00A Series positive voltage regulators are identical to the popular MC7800 Series devices, except that they are specified for only half the output current. Like the MC7800 devices, the MC78M00 three−terminal regulators are intended for local, on−card voltage regulation.
Internal current limiting, thermal shutdown circuitry and safe−area compensation for the internal pass transistor combine to make these devices remarkably rugged under most operating conditions. Maximum output current, with adequate heatsinking is 500 mA.
Features
• No External Components Required
• Internal Thermal Overload Protection
• Internal Short Circuit Current Limiting
• Output Transistor Safe−Area Compensation
• MC78M00A High Accuracy (±2%) Available for 5.0 V, 8.0 V, 12 V and 15 V
• Pb−Free Packages are Available*
MAXIMUM RATINGS (TA = 25°C, unless otherwise noted) (Note 1)
Rating |
Symbol |
Value |
Unit |
Input Voltage (5.0 V−18 V) (20 V−24V) |
VI |
35 40 |
Vdc |
Power Dissipation (Package Limitation) Plastic Package, T Suffix TA = 25°C Thermal Resistance, Junction−to−Air Thermal Resistance, Junction−to−Case Plastic Package, DT Suffix TA = 25°C Thermal Resistance, Junction−to−Air Thermal Resistance, Junction−to−Case |
PD θJA θJC
PD θJA θJC |
Internally Limited 70 5.0
Internally Limited 92 5.0 |
°C/W °C/W
°C/W °C/W |
Operating Junction Temperature Range |
TJ |
+150 |
°C |
Storage Temperature Range |
Tstg |
−65 to +150 |
°C |
Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied, damage may occur and reliability may be affected.
1. This device series contains ESD protection and exceeds the following tests:
Human Body Model 2000 V per MIL−STD−883, Method 3015.
Machine Model Method 200 V.
